Porsche Panamera 4 970 facelift (2013-2016) left rear seat entertainment module Wiring diagram
This page shows the only wiring diagram for the component.left rear seat entertainment module, which is found in the car Porsche Panamera 4 970 facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear seat entertainment module (1 of 1)
AUDIO 1 L
AUDIO 1 R
AUDIO 2 L
AUDIO 2 R
AUDIO GROUND
AUDIO L+
AUDIO R-
BLK WIRE
BLK/PNK WIRE
BLU WIRE
BRN WIRE
FUSE 11
FUSE 32
GRN WIRE
GROUND
GRY WIRE
HOT W/ SOCKET RELAY ENERGIZED
LEFT REAR SEAT ENTERTAINMENT MODULE
ORG/ WIRE
RED WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT FRONT FUSE BOX
RIGHT REAR SEAT ENTERTAINMENT MODULE
SHIELD
SUPPLY
TV TUNER
VIDEO GROUND
VIDEO SIGNAL
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Rear seat entertainment circuit -> LEFT REAR SEAT ENTERTAINMENT MODULE
