Porsche Panamera 4 970 facelift (2013-2016) can high rear heated window relay Wiring diagram
This page shows the only wiring diagram for the component.can high rear heated window relay, which is found in the car Porsche Panamera 4 970 facelift (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram can high rear heated window relay (1 of 1)
A/C CONTROL UNIT
BLK WIRE
BLOCK CIRCUIT CONDENSER
BRN WIRE
CAN HIGH
CAN HIGH REAR HEATED WINDOW RELAY
CAN LOW
COMPUTER DATA LINES SYSTEM
EXCEPT HYBRID HYBRID
FUSE 6
HOT AT ALL TIMES
ORG/BRN WIRE
ORG/GRN WIRE
ORG/VIO WIRE
REAR BCM
REAR FUSE BOX (ROW B)
REAR WINDOW HEATER
REAR WINDOW HEATER RELAY
RED/WHT WIRE
RED/YEL WIRE
Go to component -> Defogger circuit -> CAN HIGH REAR HEATED WINDOW RELAY
