Power tilt steering column circuit for Porsche Macan I (2014-2019)
Power tilt steering column circuit
ADJUSTMENT BTN GND
ADJUSTMENT BTN SIG
ADJUSTMENT CODED
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
BUTTON
COMPUTER DATA LINES SYSTEM
FUSE 5
GP-23
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HALL SENS
HALL SENS FORE/AFT +
HALL SENS HEIGHT +
HOT AT ALL TIMES
LIN
MOTOR
MOTOR + UP
MOTOR +FORE/AFT
PASSENGER SIDE FUSE BOX (ROW A)
RED/BLU WIRE
RED/VIO WIRE
RED/WHT WIRE
RIGHT END OF DASH)
STEERING COLUMN ADJUSTMENT CONTROL UNIT
STEERING COLUMN ADJUSTMENT SWITCH
STEERING COLUMN FORE/AFT ADJUSTMENT MOTOR
STEERING COLUMN HEIGHT ADJUSTMENT MOTOR
TERM 30
TERM 31
VIO/BRN WIRE
