Porsche Macan I (2014-2019) steering wheel electronics control unit Wiring diagrams
This page contains all the electrical diagrams for the component. steering wheel electronics control unit, in which he is found in the car Porsche Macan I (2014-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram steering wheel electronics control unit (1 of 3)
AIR BAG 1-
AIR BAG 2+
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRY WIRE
BRN WIRE
BRN/WHT WIRE
CAN DRIVE HIGH
CAN DRIVE LOW
COMPUTER DATA LINES SYSTEM
DISPLAY INSTRUMENT CLUSTER
DME CONTROL UNIT
E-BOX STEERING WHEEL (IN STEERING WHEEL)
FRONT BCM (LEFT END OF DASH)
FUSE 2
FUSE 4
GP-15
GP-23
GRN/VIO WIRE
GRY WIRE
GRY/WHT WIRE
HORN
HORNS SYSTEM
HOT AT ALL TIMES
HOT W/ KL 15 RELAY ENERGIZED
INSTRUMENT CLUSTER
LEFT TIPTRONIC STEERING WHEEL BUTTON
LIN
ORG/BRN WIRE
ORG/VIO WIRE
P/N SW
PARK SW
PLENUM PANEL E-BOX
RED WIRE
RED/WHT WIRE
RELEASE
RIGHT TIPTRONIC STEERING WHEEL BUTTON
SEATS SYSTEM
SELECTOR LEVER CONTROL UNIT (BASE OF SHIFT LEVER ASSEMBLY)
SELECTOR LEVER POS
SELECTOR LEVER POSITION
SELECTOR LEVER SPLY
SELECTOR LEVER TIP INFO
SENS GND
SHIFT LOCK
SIGNAL
STARTER INTER LOCK
STEERING WHEEL ELECTRONICS CONTROL UNIT
STEERING WHEEL GROUND
STEERING WHEEL HEATER
SUPPLEMENTAL RESTRAINTS SYSTEM
TEMP SENS
TEMP SENSOR SIG
TERM 15
TERM 30
TERM 31
TIP-DOWN
TIP-UP
TRANSMISSION CONTROL UNIT
TRANSMISSION OIL TEMPERATURE SENSOR
VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> A/t circuit -> STEERING WHEEL ELECTRONICS CONTROL UNIT
Wiring diagram steering wheel electronics control unit (2 of 3)
AFS CONTROL UNIT
BRN WIRE
CAN DISTRIBUTOR PLUG BRIDGE
E-BOX STEERING WHEEL
EPB CONTROL UNIT
FUEL PUMP SYSTEM CONTROL UNIT
GP-34 (RIGHT "C" PILLAR)
GP-41 (LEFT REAR OF CARGO AREA)
LEFT EXHAUST-GAS FLAP
LEFT MASTER LANE CHANGE ASSISTANT
LEFT REAR LID TAILLIGHT UNIT
LEFT TAILLIGHT ASSEMBLY
LUGGAGE COMPARTMENT SOCKET
PASM CONTROL UNIT
RDK CONTROL UNIT
REAL TOP VIEW CONTROL UNIT
REAR DIFFERENTIAL LOCK CONTROL UNIT
RIGHT EXHAUST GAS FLAP
RIGHT FRONT DOOR SILL LIGHTING
RIGHT SLAVE LANE CHANGE ASSISTANT
RIGHT TIPTRONIC STEERING WHEEL BUTTON
STEERING WHEEL ELECTRONICS CONTROL UNIT
STEERING WHEEL GROUND
TANK LEAKAGE DIAGNOSTICS
TANK SYSTEM
TRAILER SOCKET
W/ XENON
Go to component -> Ground distribution circuit (5 of 7) -> STEERING WHEEL ELECTRONICS CONTROL UNIT
Wiring diagram steering wheel electronics control unit (3 of 3)
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CAN COMFORT LOW CAN COMFORT HIGH
COMPUTER DATA LINES SYSTEM
DRIVER SIDE FUSE BOX (ROW B)
E-BOX STEERING WHEEL
FRONT BCM
FUSE 7
GP-17
GP-21
HOLDER BCM 1
HORN
HOT AT ALL TIMES
LEFT TWO-TONE HORN
LIN
ORG/BRN WIRE
ORG/GRN WIRE
RED/BLU WIRE
RED/GRY WIRE
RIGHT TWO-TONE HORN
STEERING COLUMN SWITCHING MODULE
STEERING WHEEL ELECTRONICS CONTROL UNIT
STEERING WHEEL HORN BUTTON
TWO-TONE HORNS RELAY
TWO-TONE HORNS RLY
WHT/VIO WIRE
Go to component -> Horn circuit -> STEERING WHEEL ELECTRONICS CONTROL UNIT
