Porsche Macan I (2014-2019) save memory switch Wiring diagram
This page shows the only wiring diagram for the component.save memory switch, which is found in the car Porsche Macan I (2014-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram save memory switch (1 of 1)
1, 2, OFF
ADJUSTMENT BUTTON GND
ADJUSTMENT BUTTON SIG
ADJUSTMENT CODED
BLU WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
BUTTON
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
DRIVER SIDE FUSE BOX (ROW B)
DRIVER'S DOOR CONTROL UNIT
DRIVER'S DOOR MEMORY BUTTON MODULE
FUSE 5
FUSE 8
GP-21
GP-23
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY/RED WIRE
HALL SENS
HALL SENS FORE/AFT +
HALL SENS HEIGHT +
HOT AT ALL TIMES
LIN
MEMORY OFF
MEMORY OFF BUTTON
MEMORY SET
MOTOR
MOTOR + UP
MOTOR +FORE/AFT
PASSENGER SIDE FUSE BOX (ROW A)
POWER DISTRIBUTION SYSTEM
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/WHT WIRE
RIGHT END OF DASH)
SAVE MEMORY SWITCH
SET BUTTON
STEERING COLUMN ADJUSTMENT CONTROL UNIT
STEERING COLUMN ADJUSTMENT SWITCH
STEERING COLUMN FORE/AFT ADJUSTMENT MOTOR
STEERING COLUMN HEIGHT ADJUSTMENT MOTOR
TERM 30
TERM 31
VIO/BRN WIRE
W/ KEYLESS ENTRY
WHT WIRE
YEL WIRE
Go to component -> Steering column memory circuit -> SAVE MEMORY SWITCH
