Porsche Macan Turbo I (2014-2019) Supplemental restraints circuit

AIR 1 BF + AIR 1 F - AIR BAG 1- AIR BAG 2 BF - AIR BAG 2 F - AIR BAG 2+ AIR BAG CONTROL UNIT (UNDER CENTER CONSOLE) AIR BAG GROUND AIR BAG STEERING COLUMN 1 BELT TENSIONER + BLK WIRE BLU WIRE BRN WIRE BRN/WHT WIRE CAN HI CAN LO COMPUTER DATA LINES SYSTEM DRIVER BELT TENSIONER DRIVER HEAD AIR BAG DRIVER SIDE FUSE BOX (ROW A) DRIVER SIDE HEAD AIR BAG - DRIVER SIDE REAR BELT BUCKLE DRIVER THORAX AIR BAG - DRIVER'S BUCKLE ELECTRONICS STEERING WHEEL CONTROL UNIT FUSE 2 GP-23 GRN WIRE GRY WIRE HOT W/ KL 15 RELAY ENERGIZED LEFT FRONT BELT BUCKLE LIN NEGATIVE ORG/BRN WIRE ORG/RED WIRE PASS BELT TENSIONER + PASS BUCKLE PASS SEAT POS PASS SIDE HEAD AIR BAG + PASS SIDE REAR BELT BUCKLE PASS THORAX AIR BAG + PASSENGER PASSENGER AIR BAG PASSENGER BELT FORCE LIMITER PASSENGER HEAD AIR BAG POSITIVE REAR CENTER BELT BUCKLE RED WIRE RED/WHT WIRE RIGHT FRONT SEAT POSITION SENSOR SIG STEERING COLUMN SWITCHING MODULE TERM 31 VIO WIRE WHT WIRE YEL WIRE YEL/GRY WIRE

ANTENNA GND SHIELD ANTENNA LINE BELT TENSIONER + BLU WIRE BRN WIRE CTRL UNIT 1 CTRL UNIT 2 CTRL UNIT 3 DRIVER + DRIVER BELT FORCE LIMITER DRIVER'S SEAT THORAX AIR BAG ESD GND GP-23 GP-31 GP-32 GRN WIRE GRY WIRE LEFT FRONT SEAT POSITION SENSOR LEFT REAR SEAT BELT BUCKLE LIN BUS NCA WIRE NEGATIVE PASSENGER AIR BAG OFF SWITCH PASSENGER KNEE AIR BAG POSITIVE REAR CENTER SEAT-BELT BUCKLE RED WIRE RED/WHT WIRE RIGHT FRONT PASSENGER SEAT THORAX AIR BAG RIGHT FRONT PASSENGER SIDE MAT SEAT OCCUPANCY SENSOR RIGHT REAR SEAT BELT BUCKLE SEAT OCCUPANCY DETECTION CONTROL UNIT SIG UBATT VIO WIRE VIO/WHT WIRE W/ REAR SIDE AIR BAGS WHT WIRE YEL/GRY WIRE

AIR BAG CONTROL UNIT (UNDER CENTER CONSOLE) AIR BAG ON BATTERY DISCONNECT RELAY BELT TENSIONER + BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE C-PILLAR DRIVER + C-PILLAR PASS + CAN HIGH CAN LOW CENTRAL FUSING COMPUTER DATA LINES SYSTEM DIAGNOSTIC PLUG SOCKET DISPOSAL LINE DRIVER + DRIVER DOOR DRIVER KNEE AIR BAG DRIVER SEAT POS DRIVER SIDE KNEE AIR BAG + DRIVER SIDE REAR BELT TENSIONER DRIVER SIDE THORAX AIR BAG - DRIVER'S DOOR PRESSURE SENSOR ENGINE PRE ESD GND FRONT PASSENGER SIDE REAR BELT TENSIONER GP-23 GP-31 GP-32 GRN WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES LEFT FRONT SENSOR LEFT REAR SEAT THORAX AIR BAG LEFT REAR WHEEL HOUSING SIDE IMPACT SENSOR LIN NEGATIVE ORG/BLK WIRE ORG/BRN WIRE PASS DOOR PASS SIDE SEAT BELT TENSIONER - PASS SIDE THORAX AIR BAG + PASSENGER PASSENGER AIR BAG OFF LIGHT PASSENGER AIR BAG ON LIGHT PASSENGER AIR BAG ON/OFF LIGHT PASSENGER'S SIDE + POSITIVE POWER DISTRIBUTION SYSTEM PYROTECHNICAL BATT - RED WIRE RED/WHT WIRE RIGHT FRONT BELT BUCKLE RIGHT FRONT PASSENGER DOOR PRESSURE SENSOR RIGHT FRONT SENSOR RIGHT REAR SEAT THORAX AIR BAG RIGHT REAR WHEEL HOUSING SIDE IMPACT SENSOR SIG TERM 15 VIO WIRE VIO/WHT WIRE W/ REAR SIDE AIR BAGS WHT WIRE YEL WIRE YEL/BLU WIRE YEL/RED WIRE
