Premium radio circuit, w/ bose for Porsche Macan Turbo I (2014-2019)

ANTENNA AUX 1 IN L + AUX 1 RTN AUX GND AUX IN R + AUX L + AUX R + BLK WIRE BLU WIRE BLUETOOTH HANDSET BRN WIRE CONTROL LINE DAB ANTENNA DATA DETECTION SHIELD DETECTION SIGNAL DIAGNOSTICS RESISTOR FUSE 12 GLOBAL POSITIONING SYSTEM ANTENNA GP-23 GPS HF IN GRN WIRE GRY WIRE GSM ANTENNA HND FREE MCPH - HOT AT ALL TIMES INSTRUMENT CLUSTER IPOD CHARGE GND IPOD CHARGE POWER + LEFT SIDE WINDOW ANTENNA AMPLIFIER LVDS LVDS IN + MICROPHONE MICROPHONE SHIELD NCA WIRE OPTICAL WAVEGUIDE IN OPTICAL WAVEGUIDE OUT ORG/ WIRE PCM (CENTER OF DASH) REAR FUSE BOX (ROW C) RED WIRE RED/GRY WIRE RIGHT FRONT BLUETOOTH CHARGING TRAY ROOF CONSOLE SDARS ANTENNA SHIELD SOUND SYSTEMS (OPTICAL WAVEGUIDE CIRCUIT) SOUND SYSTEMS (TV TUNER CIRCUIT) TELEPHONE HF IN TERM 30 TERM 31 UNIVERSAL AUDIO INTERFACE VIDEO GND VIDEO SIG VUSB WHT WIRE YEL WIRE

ANALOG CODE LIGHT BARRIER ANALOG CODING BUTTON ANALOG CODING BUTTON 1 ANALOG CODING BUTTON 2 ANTENNA SWITCHED O/P BLK WIRE BLU WIRE BRN WIRE BRN/WHT WIRE CAN COMFORT HIGH CAN COMFORT LOW CAN HIGH CAN LOW CENTRAL LOCK ANTENNA CENTRAL LOCK SHIELDING COMPUTER DATA LINES SYSTEM DRIVER SIDE FUSE BOX (ROW A) E-BOX STEERING WHEEL (IN STEERING WHEEL) FRONT BCM (LEFT END OF DASH) FUSE 12 FUSE 2 FUSE 3 FZV GP-17 GP-23 GP-24 HF 1 HOME LINK CONTROL UNIT HOT AT ALL TIMES HOT W/ KL 15 RELAY ENERGIZED HOT W/ SOCKETS RELAY ENERGIZED LEFT FRONT PORSCHE REAR SEAT ENTERTAINMENT LEFT STEERING WHEEL REMOTE CONTROL LEFT SWITCH PANEL LIN ORG/BRN WIRE ORG/GRN WIRE ORG/VIO WIRE PASSENGER SIDE FUSE BOX (ROW B) PCM (CENTER OF DASH) PWM CLOCK SIGNAL PWM SEARCH LIGHTING RADIO HF IN REAR FUSE BOX (ROW D) REAR FUSE BOX (ROW E) RED WIRE RED/BLK WIRE RED/GRY WIRE RED/YEL WIRE RIGHT ANTENNA AMPLIFIER RIGHT END OF DASH) RIGHT FRONT PORSCHE REAR SEAT ENTERTAINMENT RIGHT STEERING WHEEL REMOTE CONTROL RING BRAKE DIAGNOSIS SHIELD SOUND SYSTEMS (TV TUNER CIRCUIT) STEERING COLUMN SWITCHING MODULE STEERING WHEEL ELECTRONICS CONTROL UNIT SPIRAL SPRING STEERING WHEEL GROUND SUPPLY TERM 15 TERM 30 TERM 31 VIO/BRN WIRE WHT WIRE YEL WIRE

BLU WIRE BLU/BLK WIRE BLU/YEL WIRE BOSE AMPLIFIER BRN WIRE BRN/WHT WIRE CEN LSP - CENTER DASHBOARD LOUDSPEAKER DRIVER'S DOOR MID-RANGE SPEAKER DRIVER'S DOOR WOOFER EFFECT SPEAKER + FRONT PASSENGER DOOR MID-RANGE SPEAKER FRONT PASSENGER DOOR WOOFER FUSE 4 FUSE 5 GP-43 GRN WIRE GRN/BLK WIRE GRY WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES INPUT LEFT DASHBOARD LOUDSPEAKER LEFT LSP WOOFER- LEFT REAR D-PILLAR EFFECT LOUDSPEAKER LEFT REAR TWEETER LEFT REAR WOOFER LF SPEAKER (+) LR SPEAKER (+) MICROPHONE OPTICAL WAVEGUIDE IN OPTICAL WAVEGUIDE OUT ORG/ WIRE REAR FUSE BOX (ROW C) RED WIRE RED/BLU WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RF SPEAKER (+) RIGHT DASHBOARD LOUDSPEAKER RIGHT LSP WOOFER- RIGHT REAR D-PILLAR EFFECT SPEAKER RIGHT REAR TWEETER RIGHT REAR WOOFER RING BRAKE DIAGNOSIS RR SPEAKER (+) SIG SOUND SYSTEMS SUBWOOFER SUBWOOFER IN SIG TERM 30 TERM 31 TV TUNER CIRCUIT VIO WIRE VIO/BLK WIRE WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/RED WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE
