Porsche Macan Turbo I (2014-2019) w/ start/stop function w/o start/stop function Wiring diagram
This page shows the only wiring diagram for the component.w/ start/stop function w/o start/stop function, which is found in the car Porsche Macan Turbo I (2014-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ start/stop function w/o start/stop function (1 of 1)
ANALOG BUTTON
BLK WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CAN COMFORT HIGH
CAN COMFORT LOW
COMPUTER DATA LINES SYSTEM
DC/DC CONVERTER 1
E-BOX STEERING WHEEL (IN STEERING WHEEL)
ELECTRONICS STEERING WHEEL CONTROL UNIT
FUSE 3
GP-23
GROUND
HEATER
HOT AT ALL TIMES
LIN
ORG/BRN WIRE
ORG/GRN WIRE
OUTPUT TERM 30-1
PASSENGER SIDE FUSE BOX (ROW B)
POWER DISTRIBUTION SYSTEM
REAR FUSE BOX (ROW C)
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RIGHT END OF DASH)
STEERING COLUMN SWITCHING MODULE
STEERING WHEEL GROUND
STEERING WHEEL HEATING
STEERING WHEEL HEATING BUTTON
TERM 15
TERM 30
TERM 30 1
TERM 31
W/ START/STOP FUNCTION W/O START/STOP FUNCTION
Go to component: -> Heated steering wheel circuit -> W/ START/STOP FUNCTION W/O START/STOP FUNCTION
