Porsche Macan Turbo I (2014-2019) right front seat position sensor Wiring diagram
This page shows the only wiring diagram for the component.right front seat position sensor, which is found in the car Porsche Macan Turbo I (2014-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front seat position sensor (1 of 1)
AIR 1 BF +
AIR 1 F -
AIR BAG 1-
AIR BAG 2 BF -
AIR BAG 2 F -
AIR BAG 2+
AIR BAG CONTROL UNIT (UNDER CENTER CONSOLE)
AIR BAG GROUND
AIR BAG STEERING COLUMN 1
BELT TENSIONER +
BLK WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
CAN HI
CAN LO
COMPUTER DATA LINES SYSTEM
DRIVER BELT TENSIONER
DRIVER HEAD AIR BAG
DRIVER SIDE FUSE BOX (ROW A)
DRIVER SIDE HEAD AIR BAG -
DRIVER SIDE REAR BELT BUCKLE
DRIVER THORAX AIR BAG -
DRIVER'S BUCKLE
ELECTRONICS STEERING WHEEL CONTROL UNIT
FUSE 2
GP-23
GRN WIRE
GRY WIRE
HOT W/ KL 15 RELAY ENERGIZED
LEFT FRONT BELT BUCKLE
LIN
NEGATIVE
ORG/BRN WIRE
ORG/RED WIRE
PASS BELT TENSIONER +
PASS BUCKLE
PASS SEAT POS
PASS SIDE HEAD AIR BAG +
PASS SIDE REAR BELT BUCKLE
PASS THORAX AIR BAG +
PASSENGER
PASSENGER AIR BAG
PASSENGER BELT FORCE LIMITER
PASSENGER HEAD AIR BAG
POSITIVE
REAR CENTER BELT BUCKLE
RED WIRE
RED/WHT WIRE
RIGHT FRONT SEAT POSITION SENSOR
SIG
STEERING COLUMN SWITCHING MODULE
TERM 31
VIO WIRE
WHT WIRE
YEL WIRE
YEL/GRY WIRE
Go to component: -> Supplemental restraints circuit (1 of 3) -> RIGHT FRONT SEAT POSITION SENSOR
