Porsche Macan Turbo I (2014-2019) rear lin camera Wiring diagram
This page shows the only wiring diagram for the component.rear lin camera, which is found in the car Porsche Macan Turbo I (2014-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear lin camera (1 of 1)
AUDIO 2 GND
BACKUP CAMERA
BLK WIRE
BLU WIRE
BRN WIRE
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
CVBS VIDEO
DRIVER DOOR MIRROR
FRONT CAMERA
FRONT LIN CAMERA
FRONT LVDS+ CAMERA
FRONT VCC CAMERA
FUSE 6
GP-41
GRN WIRE
HOT AT ALL TIMES
LEFT LIN CAMERA
LEFT LVDS+ CAMERA
LEFT VCC CAMERA
LIN
LVDS
ORG/ WIRE
ORG/BRN WIRE
ORG/VIO WIRE
PASSENGER DOOR MIRROR
PCM
POWER
REAL TOP VIEW CONTROL UNIT
REAR FUSE BOX (ROW E)
REAR LIN CAMERA
REAR LVDS+ CAMERA
REAR VCC CAMERA
RED/WHT WIRE
RIGHT LIN CAMERA
RIGHT LVDS+ CAMERA
RIGHT VCC CAMERA
SHIELD
SIGNAL
TELEVISION TUNER
TERM 30
TERM 31
VCC
VIDEO 2
VIDEO 2 GND
VIDEO GND
VIDEO SIG
W/O TV TUNER
WHT WIRE
Go to component -> Real top view circuit -> REAR LIN CAMERA
