Porsche Macan Turbo I (2014-2019) ptc heater Wiring diagram
This page shows the only wiring diagram for the component.ptc heater, which is found in the car Porsche Macan Turbo I (2014-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ptc heater (1 of 1)
3.0L TURBO
AIR BAG GROUND
AUXILIARY HEATER CIRCULATING PUMP
BRN WIRE
ELECTRONICS STEERING WHEEL CONTROL UNIT
ENGINE LID SWITCH
ENGINE LID SWITCH 2
FRONT PASSENGER DOOR CENTRAL LOCK SAFE LED
FRONT PASSENGER DOOR CONTROL UNIT
FRONT PASSENGER DOOR LOCK
FRONT PASSENGER OUTER DOOR HANDLE SENSOR
FRONT PASSENGER OUTER DOOR HANDLE SWITCH
GP-11
GP-14 (UNDER RIGHT HEADLIGHT)
GP-17 (UNDER LEFT HEADLIGHT)
GP-22 (RIGHT KICK PANEL)
GP-25
HEADLIGHT WASHER FLUID PUMP
HOMELINK CONTROL UNIT
LEFT AUXILIARY HEADLIGHT
LEFT FRONT FOG LIGHT
LEFT FRONT TURN SIGNAL
LEFT HEADLIGHT
LEFT TWO-TONE HORN
NCA WIRE
PARKING HEATER CONTROL UNIT
PSM CONTROL UNIT
PTC HEATER
RADIATOR SHUTTER 1
REFRIGERANT PRESSURE SENSOR
RIGHT AUXILIARY HEADLIGHT
RIGHT FRONT FOG LIGHT
RIGHT FRONT TURN SIGNAL
RIGHT HEADLIGHT
RIGHT TWO-TONE HORN
Go to component: -> Ground distribution circuit (7 of 7) -> PTC HEATER
