Porsche Macan Turbo I (2014-2019) mirror ec glass gnd Wiring diagram
This page shows the only wiring diagram for the component.mirror ec glass gnd, which is found in the car Porsche Macan Turbo I (2014-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror ec glass gnd (1 of 1)
ANTI-DAZZLE INTERIOR MIRROR
BLK/YEL WIRE
BRN WIRE
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MIRROR
DRIVER SIDE FUSE BOX (ROW A)
DRIVER SIDE FUSE BOX (ROW B)
DRIVER'S DOOR CONTROL UNIT
EC MIRROR
FRONT PASSENGER DOOR CONTROL UNIT
FUSE 3
FUSE 8
FUSE 9
GP-21
GP-22
HOT AT ALL TIMES
HOT W/ KL 15 RELAY ENERGIZED
LIN
MIRROR EC GLASS
MIRROR EC GLASS GND
NCA WIRE
PASSENGER DOOR MIRROR
POWER DISTRIBUTION SYSTEM
REAR FUSE BOX (ROW C)
RED/GRN WIRE
RED/YEL WIRE
TERM 15
TERM 30
TERM 31
W/ KEYLESS ENTRY
WHT WIRE
Go to component: -> Power mirrors circuit -> MIRROR EC GLASS GND
