Porsche Macan Turbo I (2014-2019) left vent blower sensor Wiring diagram
This page shows the only wiring diagram for the component.left vent blower sensor, which is found in the car Porsche Macan Turbo I (2014-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left vent blower sensor (1 of 1)
A/C CONTROL UNIT
BLK/GRN WIRE
BLK/WHT WIRE
BRN WIRE
DRIVER SEAT CUSHION VENTILATION MOTOR
DRIVER SIDE FUSE BOX (ROW A)
DRIVER'S SEAT BACKREST VENTILATION MOTOR
FRONT PASSENGER SEAT BACKREST VENTILATION MOTOR
FRONT PASSENGER SEAT CUSHION VENTILATION MOTOR
FUSE 4
GP-31
GP-32
GP-32 (UNDER PASSENGER'S SEAT)
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRY/YEL WIRE
HOT W/ KL 15 RELAY ENERGIZED
LEFT FRONT SEAT BACKREST HEATING ELEMENT
LEFT FRONT SEAT CUSHION HEATING ELEMENT
LEFT VENT BLOWER SENSOR
LH SEAT HTR
LH SEAT TEMP SENS
LH SEAT VENTILATION
PASSENGER COMPARTMENT TEMPERATURE SENSOR
PWM
RED/BLK WIRE
RED/GRN WIRE
RH SEAT HTR
RH SEAT TEMP SENS
RH SEAT VENTILATION
RIGHT FRONT SEAT BACKREST HEATING ELEMENT
RIGHT FRONT SEAT CUSHION HEATING ELEMENT
RIGHT VENT BLOWER SENSOR
SIGNAL GROUND
TERM 30
TERM 31
Go to component: -> Front seat heater circuit -> LEFT VENT BLOWER SENSOR
