Porsche Macan Turbo I (2014-2019) hands-free microphone - Wiring diagram
This page shows the only wiring diagram for the component.hands-free microphone -, which is found in the car Porsche Macan Turbo I (2014-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hands-free microphone - (1 of 1)
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/VIO WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 8
GP-21
GRY WIRE
GRY/GRN WIRE
HANDS-FREE MICROPHONE -
HOT AT ALL TIMES
LIN
LR INTERIOR LIGHT, READING LIGHT
LR READING LIGHT
MICROPHONE NOISE DETECTION SHIELD
MICROPHONE NOISE DETECTION SIGNAL
REAR FUSE BOX (ROW D)
REAR LIGHT GROUND
REAR ORIENTATION LIGHT
REAR SYMBOL LIGHTING
RED WIRE
RED/YEL WIRE
ROOF CONSOLE
RR INTERIOR LIGHT, READING LIGHT
RR READING LIGHT
SOUND SYSTEMS
TERM 30 TRANSPORT
TERM 31
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
Go to component: -> Overhead console circuit -> HANDS-FREE MICROPHONE -
