Porsche Macan Turbo I (2014-2019) ec mirror gnd wiring diagram
This page shows the only wiring diagram for the component.ec mirror gnd, which is found in the car Porsche Macan Turbo I (2014-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
ec mirror gnd wiring diagram (1 of 1)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BRN WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BUTTON 1, 2 OFF
CAMERA GROUND
CAMERA OUTPUT
CAMERA SHIELD
CAMERA SUPPLY
CAN HIGH
CAN LOW
CHANGEOVER SWITCH MIRROR
COMPUTER DATA LINES SYSTEM
COURTESY LIGHT
CTRL SW
DRIVER DOOR MIRROR
DRIVER SIDE FUSE BOX (ROW B)
DRIVER'S DOOR BUTTON MODULE
DRIVER'S DOOR CONTROL UNIT (IN DRIVER DOOR)
DRIVER'S DOOR MEMORY BUTTON MODULE
EC MIRROR
EC MIRROR GND
FRONT PASSENGER DOOR CONTROL UNIT
FUSE 8
FUSE 9
GP-21 (LEFT KICK PANEL)
GP-22
GRN WIRE
GRN/VIO WIRE
GRY/RED WIRE
HEATING
HOT AT ALL TIMES
LCA LED -
LCA LED, DS -
LCA LED, PS +
LIN
LVDS
MEMORY OFF
MEMORY SET
MIRROR ADJUSTMENT
MIRROR DIRECTION IND
MIRROR EC GLASS
MIRROR FOLDING 1
MIRROR FOLDING 2
MIRROR FOLDING POS 1
MIRROR FOLDING POS 2
MIRROR HEATING
MIRROR SEL CTRL SW
MIRROR STATUS POS X
MIRROR STATUS POS Y
MOTOR 1
MOTOR 1/2
MOTOR 2
MOTOR SPLY
MOTOR X
MOTOR Y
NAVIGATION SYSTEM
NCA WIRE
ORG/ WIRE
PASSENGER DOOR MIRROR
POTENTIOMETER
POTENTIOMETER SPLY
POTI ENGINE 1
POTI ENGINE 2
POWER
POWER DISTRIBUTION SYSTEM
REAR FUSE BOX (ROW C)
RED/GRN WIRE
RED/YEL WIRE
RIGHT SLAVE LANE CHANGE ASSISTANT
SET BUTTON
STATUS POS X
TERM 30
TERM 31
TERM 31 POTENTI
TERM 31 POWER
TERMINAL 31
TURN SIGNAL
VIO/BLK WIRE
VIO/RED WIRE
W/ KEYLESS ENTRY
WHT WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Memory mirrors circuit -> EC MIRROR GND
