Porsche Macan Turbo I (2014-2019) driver's seat control unit Wiring diagrams

ACC CONTROL UNIT AFS CONTROL UNIT BLK/YEL WIRE BRN WIRE CAN CHAS HIGH CAN CHAS LOW CAN COM HIGH CAN COM LOW CAN CRASH HIGH CAN CRASH LOW CAN DISTRIBUTOR PLUG BRIDGE CAN HIGH CAN LOW DRIVER'S DOOR CONTROL UNIT (IN DRIVER'S DOOR) DRIVER'S SEAT CONTROL UNIT ELECTRONIC IGNITION LOCK FRONT BCM (LEFT END OF DASH) FRONT CAMERA CONTROL UNIT FRONT WIPER MOTOR FUSE 2 GP-41 GRY/BRN WIRE HOMELINK CONTROL UNIT HOT W/ KL 15 RELAY ENERGIZED LANE MASTER CHANGE ASSISTANT LIN LIN 1 LIN 2 LIN 3 ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE ORG/RED WIRE ORG/VIO WIRE RAIN SENSOR REAR FUSE BOX (ROW D) RED/WHT WIRE ROTARY LIGHT SWITCH STEERING COLUMN ADJUSTMENT CONTROL UNIT STEERING COLUMN LOCK STEERING COLUMN SWITCHING MODULE TERM 31 VIO/BRN WIRE VIO/GRN WIRE W/ XENON WHT WIRE

ADJ VENTILATE ADJ VLV 1 BLEED ADJ VLV 3 BLEED AFT ADJ 1 AFT ADJ 2 BACKREST ADJ SW BACKREST ANGLE ADJ 1 BACKREST ANGLE ADJ 2 BLK WIRE BLU WIRE BLU/BLK WIRE BLU/VIO WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE CAN HIGH CAN LOW COMPUTER DATA LINES SYSTEM DRIVER SIDE FUSE BOX (ROW C) DRIVER'S SEAT BACKREST ADJUSTMENT MOTOR DRIVER'S SEAT CONTROL UNIT DRIVER'S SEAT LUMBAR MOTORS DRV/PASS CODING FUSE 4 GP-31 GRN WIRE GRN/BLK WIRE GRN/VIO WIRE GRN/YEL WIRE GRY WIRE HALL SENS HALL SENS ADJ HOT AT ALL TIMES LUMBAR CURVATURE LUMBAR CURVATURE 1 LUMBAR CURVATURE 2 LUMBAR GND LUMBAR HEIGHT LUMBAR HEIGHT 1 LUMBAR HEIGHT 2 LUMBAR SW BACK/FWD LUMBAR SW HI/LO MTR 1 - MTR 2 - ORG/BRN WIRE ORG/GRN WIRE PUMP PUMP GND RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE SEAT ADJ SW ANGLE ADJ SEAT ADJ SW HEIGHT ADJ SEAT ADJ, AFT ADJ SW SEAT ANGLE ADJ 1 SEAT ANGLE ADJ 2 SEAT BACKREST ADJ 1 SEAT BACKREST ADJ 2 SEAT CUSHION SW SEAT DEPTH ADJ 1 SEAT DEPTH ADJ 2 SEAT DEPTH ADJ SW SEAT HEIGHT ADJ 1 SEAT HEIGHT ADJ 2 SEAT WIDTH ADJUSTMENT COMPRESSOR SEAT WIDTH ADJUSTMENT VALVE BLOCK SW BACKREST ANGLE ADJ TERMINAL 30 TERMINAL 31 VIO WIRE VIO/GRN WIRE VIO/YEL WIRE VLV 2 VENTILATE VLV 4 VENTILATE VLV BLOCK GND WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/YEL WIRE WIDTH ADJ BLEED WIDTH ADJ VENT YEL/BLK WIRE YEL/GRY WIRE

ALARM SIREN BLIND ROOF GLASS MOTOR BLK WIRE COMPASS DRIVER SIDE DASHBOARD HOLDER (FUSE HOLDER C) DRIVER SIDE DASHBOARD HOLDER (FUSE HOLDER D) DRIVER SIDE FUSE BOX (ROW C) DRIVER'S SEAT CONTROL UNIT EMC CONDENSER 1 FRESH AIR FAN MOTOR FROM CENTRAL FUSING (DIAGRAM 1 OF 6) FROM DC/DC CONVERTER 1 (DIAGRAM 2 OF 6) FROM DRIVER SIDE FUSE BOX (ROW B) (DIAGRAM 4 OF 6) FROM JUMP START POINT (DIAGRAM 1 OF 6) FRONT BCM FRONT PASSENGER SEAT ADJUSTMENT OUTPUT CONTROL UNIT FRONT WIPER MOTOR FUSE 1 FUSE 10 FUSE 11 FUSE 12 FUSE 2 FUSE 3 FUSE 4 FUSE 5 FUSE 6 FUSE 7 FUSE 8 FUSE 9 GLASS ROOF MOTOR 1 HOLDER BCM 1 INSTRUMENT CLUSTER N/A PASSENGER SIDE FUSE BOX (ROW B) PLENUM PANEL E-BOX FUSE HOLDER A PLENUM PANEL E-BOX FUSE HOLDER B PSM CONTROL UNIT PTC RELAY 1 PTC RELAY 2 RED WIRE RED/ GRY WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT END OF DASH) SECONDARY AIR PUMP RELAY 1 STARTER RELAY 2 STEERING COLUMN SWITCHING MODULE TANK LEAKAGE DIAGNOSTICS TO DRIVER SIDE FUSE BOX (ROW B) (DIAGRAM 4 OF 6) TO E-BOX TRANSFER PIN 2 (DIAGRAM 6 OF 6) W/O START/STOP FUNCTION W/ START/STOP FUNCTION
