Porsche Macan Turbo I (2014-2019) driver's seat backrest ventilation motor Wiring diagrams
This page contains all the electrical diagrams for the component. driver's seat backrest ventilation motor, in which he is found in the car Porsche Macan Turbo I (2014-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram driver's seat backrest ventilation motor (1 of 2)
A/C CONTROL UNIT
BLK/GRN WIRE
BLK/WHT WIRE
BRN WIRE
DRIVER SEAT CUSHION VENTILATION MOTOR
DRIVER SIDE FUSE BOX (ROW A)
DRIVER'S SEAT BACKREST VENTILATION MOTOR
FRONT PASSENGER SEAT BACKREST VENTILATION MOTOR
FRONT PASSENGER SEAT CUSHION VENTILATION MOTOR
FUSE 4
GP-31
GP-32
GP-32 (UNDER PASSENGER'S SEAT)
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRY/YEL WIRE
HOT W/ KL 15 RELAY ENERGIZED
LEFT FRONT SEAT BACKREST HEATING ELEMENT
LEFT FRONT SEAT CUSHION HEATING ELEMENT
LEFT VENT BLOWER SENSOR
LH SEAT HTR
LH SEAT TEMP SENS
LH SEAT VENTILATION
PASSENGER COMPARTMENT TEMPERATURE SENSOR
PWM
RED/BLK WIRE
RED/GRN WIRE
RH SEAT HTR
RH SEAT TEMP SENS
RH SEAT VENTILATION
RIGHT FRONT SEAT BACKREST HEATING ELEMENT
RIGHT FRONT SEAT CUSHION HEATING ELEMENT
RIGHT VENT BLOWER SENSOR
SIGNAL GROUND
TERM 30
TERM 31
Go to component -> Front seat heater circuit -> DRIVER'S SEAT BACKREST VENTILATION MOTOR
Wiring diagram driver's seat backrest ventilation motor (2 of 2)
BRN WIRE
DRIVER SEAT CONTROL UNIT
DRIVER SEAT CUSHION VENTILATION MOTOR
DRIVER'S SEAT BACKREST VENTILATION MOTOR
DRIVER'S SEAT THORAX AIR BAG
FRONT PASSENGER SEAT ADJUSTMENT OUTPUT CONTROL UNIT
FRONT PASSENGER SEAT BACKREST VENTILATION MOTOR
FRONT PASSENGER SEAT CONTROL UNIT
FRONT PASSENGER SEAT CUSHION VENTILATION MOTOR
GP-31
GP-32
LEFT FRONT SEAT BACKREST HEATING ELEMENT
LEFT FRONT SEAT CUSHION HEATING ELEMENT
LEFT REAR DOOR CONTROL UNIT
LEFT REAR DOOR LOCK
LEFT REAR FOOTWELL LIGHT
LEFT REAR OUTER DOOR HANDLE SENSOR
LEFT REAR OUTER DOOR HANDLE SWITCH
LEFT REAR SEAT CUSHION HEATING ELEMENT
LEFT REAR SEAT THORAX AIR BAG
RIGHT FRONT PASSENGER SEAT THORAX AIR BAG
RIGHT FRONT SEAT BACKREST HEATING ELEMENT
RIGHT FRONT SEAT CUSHION HEATING ELEMENT
RIGHT REAR DOOR CONTROL UNIT
RIGHT REAR DOOR LOCK
RIGHT REAR FOOTWELL LIGHT
RIGHT REAR OUTER DOOR HANDLE SENSOR
RIGHT REAR OUTER DOOR HANDLE SWITCH
RIGHT REAR SEAT CUSHION HEATING ELEMENT
RIGHT REAR SEAT THORAX AIR BAG
SUPERCHARGER LEVEL CONTROL
W/ MEMORY
W/ REAR SIDE AIR BAG
W/O MEMORY
WHT WIRE
Go to component -> Ground distribution circuit (3 of 7) -> DRIVER'S SEAT BACKREST VENTILATION MOTOR
