Porsche Macan Turbo I (2014-2019) adjust back Wiring diagram
This page shows the only wiring diagram for the component.adjust back, which is found in the car Porsche Macan Turbo I (2014-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram adjust back (1 of 1)
ADJ BACK
ADJ FWD
ADJUST BACK
ADJUST FWD
AFT ADJ 1
AFT ADJ 2
ANGLE ADJ 1
ANGLE ADJ 2
BLU WIRE
BRN WIRE
FRONT PASSENGER SEAT ADJUSTMENT OUTPUT CONTROL UNIT
FRONT PASSENGER SEAT BACKREST ADJUSTMENT MOTOR
FUSE 11
FUSE 5
GP-32
GRN WIRE
GRY WIRE
HEIGHT ADJ 1
HEIGHT ADJ 2
HOT AT ALL TIMES
PASSENGER SIDE FUSE BOX (ROW B)
PIPE FRAME SERVO MOTOR
REAR FUSE BOX (ROW B)
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RIGHT END OF DASH)
SEAT FRT HIGH
SEAT FRT LOW
SEAT REAR HIGH
SEAT REAR LOW
TERMINAL 30
TERMINAL 31
VIO WIRE
Go to component: -> Passenger power seat circuit -> ADJUST BACK
