Porsche Macan Turbo I (2014-2019) acc relay rear relay support Wiring diagram
This page shows the only wiring diagram for the component.acc relay rear relay support, which is found in the car Porsche Macan Turbo I (2014-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram acc relay rear relay support (1 of 1)
ACC CONTROL UNIT
ACC RELAY REAR RELAY SUPPORT
BLK/BLU WIRE
BLK/RED WIRE
BRN WIRE
CENTER CONSOLE CIGAR LIGHTER
CENTER CONSOLE STORAGE BIN SOCKET
EPB CONTROL UNIT
FROM DC/DC CONVERTER 1 (DIAGRAM 2 OF 6)
FROM FRONT BCM (DIAGRAM 2 OF 6)
FROM REAR FUSE BOX (ROW B) (DIAGRAM 1 OF 6)
FROM REAR FUSE BOX (ROW E) (DIAGRAM 2 OF 6)
FUSE 1
FUSE 10
FUSE 11
FUSE 12
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 9
GATEWAY CONTROL UNIT
GP-23
GP-41
GP-42
GRY/BLK WIRE
GRY/RED WIRE
GRY/WHT WIRE
KL 15 RELAY
LEFT FRONT PORSCHE REAR SEAT ENTERTAINMENT
LUGGAGE COMPARTMENT SOCKET
N/A
PASM COMPRESSOR RELAY
REAR CENTER CONSOLE PLUG SOCKET 1
REAR DIFFERENTIAL LOCK CONTROL UNIT
REAR FUSE BOX (ROW A)
REAR FUSE BOX (ROW D)
REAR RELAY SUPPORT
REAR WINDOW MODULE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT PORSCHE REAR SEAT ENTERTAINMENT
SOCKETS RELAY
TERM 30
TERM 31
TO DRIVER SIDE FUSE BOX (ROW A) (DIAGRAM 6 OF 6)
TO PASSENGER SIDE FUSE BOX (ROW A) (DIAGRAM 4 OF 6)
TRAILER HITCH CONTROL UNIT
W/O START/STOP FUNCTION W/ START/STOP FUNCTION
Go to component -> Power distribution circuit (3 of 6) -> ACC RELAY REAR RELAY SUPPORT
