Porsche Macan Turbo I (2014-2019) acc relay Wiring diagrams

ACC CONTROL UNIT ACC RELAY ACCELERATOR GND 1 ACCELERATOR GND 2 ACCELERATOR PEDAL ACTL VLV 1 ACTL VLV 2 BLK WIRE BLK/RED WIRE BLU/BLK WIRE BLU/GRN WIRE BRAKE PEDAL SW BRN WIRE BRN/GRN WIRE BRN/YEL WIRE CAN COMFORT HIGH CAN COMFORT LOW CAN DRIVE HIGH CAN DRIVE LOW CAN HIGH CAN LOW COMPUTER DATA LINES SYSTEM CRUISE CTRL MAIN SW DME CONTROL UNIT (LEFT REAR ENGINE COMPT) FUSE 2 FUSE 6 FUSE 7 FUSE 9 GND POTI GND PTNOMTR 1 GND PTNOMTR 2 GP-15 GP-21 GP-23 GP-42 GRN WIRE GRY/BLK WIRE GRY/BLU WIRE HOT W/ DME RELAY 1 ENERGIZED HOT W/ KL 15 RELAY ENERGIZED INSTRUMENT CLUSTER INTERLOCK - MTR ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE ORG/VIO WIRE OUTPUT P/N START RELEASE PLENUM PANEL E-BOX REAR FUSE BOX (ROW D) REAR RELAY SUPPORT RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE SIG (1) SIG (2) STARTER STEERING COLUMN SWITCHING MODULE STOP LIGHT SWITCH TERM 15 TERM 31 TERM 87 THROTTLE VALVE ADJUSTMENT UNIT (ON THROTTLE BODY ASSEMBLY) THRTL ACTR VLV 1 THRTL ACTR VLV 2 THRTL VLV GND THRTL VLV MTR - TRANSMISSION CONTROL UNIT W/O START STOP FUNCTION W/ START STOP FUNCTION YEL/BLK WIRE YEL/BLU WIRE YEL/GRY WIRE

ACC RELAY BACKUP CAMERA CONTROL UNIT BATTERY SENSOR BLK WIRE BOSE AMPLIFIER BRN WIRE BURMESTER AMPLIFIER DC/DC CONVERTER FUEL METERING PUMP GP-42 GP-43 GP-45 GP-46 GP-52 HIGH MOUNTED STOP LIGHT LEFT BUMPER TAILLIGHT ASSEMBLY LEFT NUMBER PLATE LIGHT LEFT REAR WINDOW BLOCKING CIRCUIT OUTER REAR LID BUTTON PARK ASSISTANCE CONTROL UNIT PASSENGER BUTTON PLUG POWER LIFTGATE BUTTON W/ PAS POWER LIFTGATE CONTROL UNIT REAR ADAPTER RELAY 1 REAR BCM REAR RELAY SUPPORT REAR WINDOW HEATER RELAY REAR WINDOW MODULE RIGHT BUMPER TAILLIGHT ASSEMBLY RIGHT NUMBER PLATE LIGHT RIGHT REAR LID TAILLIGHT UNIT RIGHT REAR WINDOW BLOCKING CIRCUIT RIGHT TAILLIGHT ASSEMBLY SOCKETS RELAY TAILGATE LOCK MOTOR TAILGATE LOCK MOTOR CLOSING AID TELESTART RECEIVER AUXILIARY HEATER TELEVISION TUNER TRAILER HITCH CONTROL UNIT
