Porsche Macan GTS I facelift 2 (2021-2024) term 31 poti Wiring diagrams
This page contains all the electrical diagrams for the component. term 31 poti, in which he is found in the car Porsche Macan GTS I facelift 2 (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram term 31 poti (1 of 2)
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BRN WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BUTTON 1, 2 OFF
CAN HIGH
CAN LOW
CHANGEOVER SWITCH MIRROR
COMPUTER DATA LINES SYSTEM
COURTESY LIGHT
CTRL SW
DRIVER DOOR MIRROR
DRIVER SIDE FUSE BOX (ROW B)
DRIVER'S DOOR BUTTON MODULE
DRIVER'S DOOR CONTROL UNIT
DRIVER'S DOOR MEMORY BUTTON MODULE
EC MIRROR
EC MIRROR GND
EHT
FRONT PASSENGER DOOR CONTROL UNIT
FUSE 8
FUSE 9
GP-21 (LEFT KICK PANEL)
GP-22
GRN WIRE
GRN/VIO WIRE
GRY/RED WIRE
HEATING
HOT AT ALL TIMES
LCA LED -
LCA LED LE
LCA LED, RI+
LEFT SLAVE LANE CHANGE ASSISTANT
MEMORY OFF
MEMORY SET
MIRROR ADJUSTMENT
MIRROR DIRECTION IND
MIRROR EC GLASS
MIRROR FOLDING 1
MIRROR FOLDING 2
MIRROR FOLDING POS 1
MIRROR FOLDING POS 2
MIRROR HEATING
MIRROR SEL CTRL SW
MIRROR STATUS POS X
MIRROR STATUS POS Y
MOTOR 1
MOTOR 1/2
MOTOR 2
MOTOR SPLY
MOTOR X
MOTOR Y
NAVIGATION SYSTEM
NCA WIRE
ORG/ WIRE
PASSENGER DOOR MIRROR
POTENTIOMETER
POTENTIOMETER SPLY
POTI ENGINE 1
POTI ENGINE 2
POWER
POWER DISTRIBUTION SYSTEM
REAR FUSE BOX (ROW C)
RED/GRN WIRE
RED/YEL WIRE
RIGHT SLAVE LANE CHANGE ASSISTANT
SET BUTTON
STATUS POS G
STATUS POS X
TERM 30
TERM 31
TERM 31 POTI
TERM 31 POWER
TERMINAL 31
TURN SIGNAL
VIO/BLK WIRE
VIO/RED WIRE
W/ KEYLESS ENTRY
WHT WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Memory mirrors circuit -> TERM 31 POTI
