Porsche Macan GTS I facelift 2 (2021-2024) term 30 htd seats Wiring diagram
This page shows the only wiring diagram for the component.term 30 htd seats, which is found in the car Porsche Macan GTS I facelift 2 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram term 30 htd seats (1 of 1)
BACKREST HEATING ELEMENT
BLK/WHT WIRE
BLK/YEL WIRE
BOLSTER HEATING
BRN WIRE
FUSE 8
GP-23 (LEFT FRONT OF CENTER CONSOLE)
GP-31 (UNDER DRIVER'S SEAT)
GP-32 (UNDER PASSENGER'S SEAT)
GROUND
HEATING ELEMENT BACKREST
HOT AT ALL TIMES
LEFT REAR BACKREST BOLSTER HEATING ELEMENT
LEFT REAR SEAT BACKREST HEATING ELEMENT
LEFT REAR SEAT CUSHION HEATING ELEMENT
LEFT REAR SIDE BOLSTER HEATING ELEMENT
LEFT SEAT HTR
LEFT SEAT TEMP
NCA WIRE
REAR FUSE BOX (ROW C)
REAR OPERATING, A/C UNIT
RED/BLK WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT REAR BACKREST BOLSTER HEATING ELEMENT
RIGHT REAR SEAT BACKREST HEATING ELEMENT
RIGHT REAR SEAT CUSHION HEATING ELEMENT
RIGHT REAR SIDE BOLSTER HEATING ELEMENT
RIGHT SEAT HTR
RIGHT SEAT TEMP
SIDE BOLSTER HEATING
SIGNAL GND
TERM 30 HTD SEATS
TERM 31
Go to component -> Rear seat heater circuit -> TERM 30 HTD SEATS
