Porsche Macan GTS I facelift 2 (2021-2024) seat height adj 2 seat height adj 1 Wiring diagram
This page shows the only wiring diagram for the component.seat height adj 2 seat height adj 1, which is found in the car Porsche Macan GTS I facelift 2 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram seat height adj 2 seat height adj 1 (1 of 1)
ADJ BACK
ADJ FWD
ADJUST BACK
ADJUST FWD
AFT ADJ 1
AFT ADJ 2
ANGLE ADJ 1
ANGLE ADJ 2
BLU WIRE
BRN WIRE
FRONT PASSENGER SEAT ADJUSTMENT OUTPUT CONTROL UNIT
FRONT PASSENGER SEAT BACKREST ADJUSTMENT MOTOR
FUSE 11
FUSE 5
GP-32
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ BATTERY DISCONNECT RELAY ENERGIZED
PASSENGER SIDE FUSE BOX (ROW B)
REAR FUSE BOX (ROW B)
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RIGHT END OF DASH)
RIGHT PIPE FRAME SERVO MOTOR
SEAT FRT HIGH
SEAT FRT LOW
SEAT HEIGHT ADJ 2 SEAT HEIGHT ADJ 1
SEAT REAR HIGH
SEAT REAR LOW
TERMINAL 30
TERMINAL 31
VIO WIRE
Go to component -> Passenger power seat circuit -> SEAT HEIGHT ADJ 2 SEAT HEIGHT ADJ 1
