Porsche Macan GTS I facelift 2 (2021-2024) mirr term 31 pwr Wiring diagram
This page shows the only wiring diagram for the component.mirr term 31 pwr, which is found in the car Porsche Macan GTS I facelift 2 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirr term 31 pwr (1 of 1)
BACKUP LIGHT
BLK/BLU WIRE
BLU/RED WIRE
BLU/VIO WIRE
BRAKE LIGHT OUTPUT
BRN WIRE
BRN/WHT WIRE
CAN HIGH
CAN LOW
COMPUTER DATA LINES SYSTEM
DIAGNOSTICS
DIAGNOSTICS BUMPER
DIAGNOSTICS REAR LID
DIR INDICATOR OUTPUT
DRIVER SIDE FUSE BOX (ROW C)
DRIVER'S DOOR CONTROL UNIT
FUSE 10
FUSE 11
FUSE 3
GP-42
GP-45
GRN WIRE
GRN/BRN WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/YEL WIRE
HEADLIGHTS SYSTEM
HIGH MOUNTED STOP LIGHT
HOT AT ALL TIMES
LEFT TURN SIGNAL REPEATER BULB
MIRR DIR IND
MIRR TERM 31 PWR
NEGATIVE
OUTPUT BACKUP LIGHT
PASSENGER SIDE FUSE BOX (ROW A)
POSITIVE
REAR FOG LIGHT
REAR FOG LIGHT OUTPUT
REAR FUSE BOX (ROW B)
RED/BLK WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT BUMPER TAILLIGHT ASSEMBLY
RIGHT END OF DASH)
RIGHT NUMBER PLATE LIGHT
RIGHT TAILLIGHT ASSEMBLY
SIDE MARKER LIGHT
STOP LIGHT
TAILLIGHT
TAILLIGHT OUTPUT
TERM 31
TURN SIGNAL
VIO/BLK WIRE
VIO/GRN WIRE
VIO/GRY WIRE
WHT WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Exterior lamps circuit (2 of 3) -> MIRR TERM 31 PWR
