Porsche Macan GTS I facelift 2 (2021-2024) lh seat temp sens Wiring diagram
This page shows the only wiring diagram for the component.lh seat temp sens, which is found in the car Porsche Macan GTS I facelift 2 (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lh seat temp sens (1 of 1)
A/C CONTROL UNIT
BLK/GRN WIRE
BLK/WHT WIRE
BRN WIRE
DRIVER SEAT CUSHION VENTILATION MOTOR
DRIVER SIDE FUSE BOX (ROW A)
DRIVER'S SEAT BACKREST VENTILATION MOTOR
FUSE 4
GP-31
GP-32
GP-32 (UNDER PASSENGER'S SEAT)
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
HOT W/ KL 15 RELAY ENERGIZED
LEFT FRONT SEAT BACKREST HEATING ELEMENT
LEFT FRONT SEAT CUSHION HEATING ELEMENT
LEFT VENT BLOWER SENSOR
LH SEAT HTR
LH SEAT TEMP SENS
LH SEAT VENTILATION
PWM
RED/BLK WIRE
RED/GRN WIRE
RH SEAT HTR
RH SEAT TEMP SENS
RH SEAT VENTILATION
RIGHT FRONT PASSENGER SEAT BACKREST VENTILATION MOTOR
RIGHT FRONT PASSENGER SEAT CUSHION VENTILATION MOTOR
RIGHT FRONT SEAT BACKREST HEATING ELEMENT
RIGHT FRONT SEAT CUSHION HEATING ELEMENT
RIGHT VENT BLOWER SENSOR
SIGNAL
TERM 30
TERM 31
Go to component -> Front seat heater circuit -> LH SEAT TEMP SENS
