Porsche Macan GTS I facelift 2 (2021-2024) interior sound actuator Wiring diagrams
This page contains all the electrical diagrams for the component. interior sound actuator, in which he is found in the car Porsche Macan GTS I facelift 2 (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram interior sound actuator (1 of 5)
Go to component -> Active bodyworks circuit -> INTERIOR SOUND ACTUATOR
Wiring diagram interior sound actuator (2 of 5)
2.0L TURBO
2.9L TURBO
A/C CONTROL UNIT
AIR BAG CONTROL UNIT
ANTI-DAZZLE INTERIOR MIRROR
BACKUP CAMERA CONTROL UNIT
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
CAN DRIVE HIGH
CAN DRIVE LOW
CAN HIGH
CAN LOW
CAN MMI HIGH
CAN MMI LOW
COMPASS (IF EQUIPPED) (CENTER OF DASH)
DIAGNOSTIC PLUG SOCKET
DISP LINE ACL
DME CONTROL UNIT
FUSE 1
FUSE 8
GLASS ROOF BLIND MOTOR
GLASS ROOF MOTOR (CENTER FRONT OF ROOF)
GP-23
GRY/RED WIRE
HIGH CENTRAL PROCESSOR
HOT AT ALL TIMES
HOT W/ KL 15 RELAY ENERGIZED
INSTRUMENT CLUSTER
INTERIOR SOUND ACTUATOR
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/VIO WIRE
PARKING ASSIST CONTROL UNIT
PARKING HEATER CONTROL UNIT
PASSENGER SIDE FUSE BOX (ROW A)
RDK CONTROL UNIT
REAL TOP VIEW CONTROL UNIT (LEFT SIDE OF CARGO AREA)
RED/YEL WIRE
RIGHT END OF DASH)
ROOF CONSOLE
TRANSMISSION CONTROL UNIT
Go to component -> Computer data lines circuit (3 of 3) -> INTERIOR SOUND ACTUATOR
Wiring diagram interior sound actuator (3 of 5)
2.0L TURBO
2.9L TURBO
2/3-WAY VALVE
A/C COMPRESSOR VALVE +
ACC CONTROL UNIT
AIR QUALITY SENSOR
ALARM SIREN
ANTI-DAZZLE INTERIOR MIRROR
BLIND ROOF GLASS MOTOR
BRAKE BOOSTER
BRAKE FLUID SENSOR
BRN WIRE
COOLING WATER SHUT OFF VALVE
DRIVER'S DOOR CENTRAL LOCK SAFE LED
DRIVER'S DOOR CONTROL UNIT
DRIVER'S DOOR LOCK
DRIVER'S OUTER DOOR HANDLE SENSOR
DRIVER'S OUTER DOOR HANDLE SWITCH
FRONT BCM
FRONT CAMERA CONTROL UNIT
GLASS ROOF 1 MOTOR
GP-21 (LEFT KICK PANEL)
GRY/BLK WIRE
HOLDER BCM 1
INTERIOR SOUND ACTUATOR
LEFT FRONT BRAKE PAD WEAR INDICATOR
LEFT FRONT DOOR SILL LIGHTING
RAIN SENSOR
ROOF CONSOLE
THEFT PROTECTION ALARM HORN
W/ KEYLESS ENTRY
WHT WIRE
Go to component -> Ground distribution circuit (1 of 7) -> INTERIOR SOUND ACTUATOR
Wiring diagram interior sound actuator (4 of 5)
AFS CONTROL UNIT
AIR BAG CONTROL UNIT
AIR QUALITY SENSOR
ALL-WHEEL DRIVE CONTROL UNIT
ANTI-DAZZLE INTERIOR MIRROR
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/VIO WIRE
DME CONTROL UNIT
DME RELAY 1
DRIVER SEAT CUSHION VENTILATION MOTOR
DRIVER SIDE FUSE BOX (ROW A)
DRIVER'S SEAT BACKREST VENTILATION MOTOR
E-BOX TRANSFER PIN 2
E-STEERING CONTROL UNIT
ENGINE RELAY (2.0L TURBO)
ERA-GLONASS CONTROL UNIT
ERA-GLONASS DIAGNOSTIC PLUG SOCKET
FROM DRIVER SIDE FUSE BOX (ROW C) (DIAGRAM 5 OF 6)
FROM KL 15 RELAY (DIAGRAM 3 OF 6)
FRONT CAMERA CONTROL UNIT
FRONT PASSENGER SEAT BACKREST VENTILATION MOTOR
FRONT PASSENGER SEAT CUSHION VENTILATION MOTOR
FUSE 1
FUSE 10
FUSE 11
FUSE 12
FUSE 16
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
GATEWAY CONTROL UNIT
GRY/RED WIRE
HOMELINK CONTROL UNIT
INTERIOR SOUND ACTUATOR
LEFT HEADLIGHT
LEFT MASTER LANE CHANGE ASSISTANT
PARKING ASSIST CONTROL UNIT
PASSENGER AIR BAG ON/OFF LIGHT
PLENUM PANEL E-BOX
PSM CONTROL UNIT
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
REFRIGERANT PRESSURE SENSOR
RIGHT HEADLIGHT
RIGHT SLAVE LANE CHANGE ASSISTANT
SEAT OCCUPANCY DETECTION CONTROL UNIT
STARTER RELAY 1
STARTER RELAY 2
TRANSMISSION CONTROL UNIT
VTS CONTROL UNIT
W/ A/C SEAT FRONT SEAT VENTILATION
W/ XENON
YEL WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (6 of 6) -> INTERIOR SOUND ACTUATOR
Wiring diagram interior sound actuator (5 of 5)
ACTUATOR
ACTUATOR - TERM 15
BLK/RED WIRE
BLU WIRE
BLU/GRN WIRE
BRN WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/VIO WIRE
BRN/WHT WIRE
CAN COMFORT HIGH
CAN COMFORT LOW
CAN DRIVE HIGH
CAN DRIVE LOW
COMPUTER DATA LINES SYSTEM
COOLANT TEMPERATURE SENDER CYLINDER HEAD
COOLING FANS SYSTEM
CRUISE CONT MAIN SW
CRUISE CONTROL SYSTEM
DME CONTROL UNIT (LEFT REAR ENGINE COMPT)
DRIVER SIDE FUSE BOX (ROW A)
ENGINE RELAY
ENGINE TEMPERATURE REGULATION TEMPERATURE SENDER (CRANKCASE)
FUEL PUMP
FUSE 3
GP-21
GRN WIRE
GRN/GRY WIRE
GRY WIRE
GRY/RED WIRE
HOT W/ KL 15 RELAY ENERGIZED
INTERIOR SOUND ACTUATOR
INTERIOR-SOUND ACTUATOR PULSE SENDER
LEFT EXHAUST-GAS FLAP
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
PARK/NEUTRAL
PARTICULATE FILTER 1
RADIATOR FAN 1 PWM
RADIATOR FAN 2 PWM
RADIATOR OUTLET
REAR BCM
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT EXHAUST GAS FLAP
START RELEASE
STARTER RELAY 1
STARTER RELAY 2
STARTING/ CHARGING SYSTEM
STOP LIGHT SW
STOP LT SW
TANK LEAK DIAG HEATER
TANK LEAK DIAG VLV
TERM 31
TERMINAL 50 FEEDBACK
TRAILER HITCH CONTROL UNIT
TRANSMISSIONS SYSTEM
VIO/BLU WIRE
VIO/GRN WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 2.9l turbo (7 of 9) -> INTERIOR SOUND ACTUATOR
