Charging circuit for Porsche Cayman 987 facelift (2009-2012)
Charging circuit
B+ PLUG SOCKET (RIGHT SIDE OF TRANSMISSION)
BATTERY
BLK WIRE
BRN/WHT WIRE
COOLING WATER FAN CONTROL UNIT
CURRENT DISTRIBUTOR (BEHIND RIGHT SIDE OF DASH)
DME CONTROL MODULE
GENERATOR
GENERATOR PWM
GRN/BLU WIRE
GROUND DISTRIBUTION SYSTEM
MIDI FUSE (EXHAUST)
POWER DISTRIBUTION SYSTEM
RED WIRE
STARTER
VEHICLE ELECTRICAL SYSTEM CONTROL UNIT
