Headlights circuit, with xenon lamps for Porsche Cayman 987 facelift (2009-2012)

1 5 GND 3 6 BATT GND 4 5 7 10 11 23 24 15 16 17 20 25 26 27 33 40 R LOW BEAM R HIGH BEAM ADDITIONAL HIGH BEAMS ADDITIONAL HIGH BEAMS TURN SIGNAL BLK WIRE BLU WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM FLAP FRONT END CONTROL UNIT (RIGHT SIDE OF FRONT LUGGAGE COMPT) FUSE FUSE FUSE FUSE HOLDER C GND L LOW BEAM L HIGH BEAM GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES CURRENT DISTRIBUTOR (BEHIND RIGHT SIDE OF DASH) HOT W/ TERMINAL 15 RELAY ENERGIZED ILLUM LEFT FRONT HEADLIGHT VERTICAL AIMING CONTROL SENSOR LEFT HEADLIGHT ASSEMBLY LIGHT SWITCH LOW BEAM ORG/ WIRE R FRONT FOG LT L FRONT FOG LT R H/L BEAM SPLY V VERTICAL SENS GND RED WIRE RED/GRN WIRE RED/WHT WIRE RIGHT HEADLIGHT ASSEMBLY SIGNAL STEPPER MOTOR TERM 15 LOW BEAM SW TURN SIGNAL VEHICLE ELECTRICAL SYSTEM CONTROL UNIT WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/GRN WIRE YEL/RED WIRE YEL/WHT WIRE

1 2 FOG LIGHT GND 2 1 GND SIDE MARKER LT 2 1 GND SIDE MARKER RT 3 2 1 GND DRL SIDE MARKER LT 3 2 1 GND DRL SIDE MARKER RT BLU WIRE BRN WIRE COUPE CURRENT DISTRIBUTOR (BEHIND RIGHT SIDE OF DASH) EMERGENCY POWER SUPPLY RELAY 1 FUSE GRN WIRE HOT AT ALL TIMES LEFT FRONT DAYTIME RUNNING LIGHTS LEFT FRONT FOG LIGHT POWER DISTRIBUTION SYSTEM RED WIRE RED/GRN WIRE RIGHT FRONT DAYTIME RUNNING LIGHTS RIGHT FRONT FOG LIGHT W/ DRL W/O DRL WHT/ORG WIRE YEL WIRE YEL/GRN WIRE YEL/WHT WIRE
