Porsche Cayman 987 facelift (2009-2012) weight pdk recognition control unit control unit Wiring diagram
This page shows the only wiring diagram for the component.weight pdk recognition control unit control unit, which is found in the car Porsche Cayman 987 facelift (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram weight pdk recognition control unit control unit (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
COMBINED STEERING WHEEL MODULE
COOLING WATER FAN CONTROL UNIT
CURRENT DISTRIBUTOR (BEHIND RIGHT SIDE OF
DASH)
DIAGNOSIS PLUG SOCKET
ENGINE COMPARTMENT FAN HIGH RELAY
FROM
FRONT END CONTROL UNIT
FUSE
FUSE FUSE
FUSE HOLDER B
FUSE HOLDER E (DIAGRAM 1 OF 5)
FUSE HOLDER F FUSE
GENERATOR B+ PLUG SOCKET (RIGHT SIDE OF TRANSMISSION)
GRN WIRE
HEADLIGHT WASHER RELAY RELAY SUPPORT 1 (UNDER LEFT SIDE OF DASH, IN FOOTWELL)
HEATER RELAY
INSTRUMENT CLUSTER
INTERIOR SENSOR
LEFT ALARM MEMORY SIREN SEAT CONTROL UNIT (NOT USED)
MIDI FUSE (EXHAUST)
ORG/ WIRE
PARK ASSIST CONTROL UNIT
RDK CONTROL UNIT
RED WIRE
RED/BLK WIRE
RELAY SUPPORT 1 (UNDER LEFT SIDE OF DASH, IN FOOTWELL)
RELAY SUPPORT 2 (LEFT SIDE OF REAR LUGGAGE COMPT)
RIGHT MEMORY SEAT CONTROL UNIT
SELECTOR LEVER CONTROL UNIT
SPORT CHRONO
STARTER
TILT SENSOR
TO EMERGENCY POWER SUPPLY RELAY 1 (DIAGRAM 3 OF 5)
TO MFI-DI RELAY (DIAGRAM 4 OF 5)
TO MICRO RELAY (DIAGRAM 4 OF 5)
TO TERMINAL 15 RELAY (DIAGRAM 3 OF 5)
VEHICLE ELECTRICAL SYSTEM CONTROL UNIT
WEIGHT PDK RECOGNITION CONTROL UNIT CONTROL UNIT
WHT WIRE
Go to component -> Power distribution circuit (2 of 5) -> WEIGHT PDK RECOGNITION CONTROL UNIT CONTROL UNIT
