Porsche Cayman 987 facelift (2009-2012) w/ on board refueling vapour recovery w/o on board refueling vapour recovery Wiring diagram
This page shows the only wiring diagram for the component.w/ on board refueling vapour recovery w/o on board refueling vapour recovery, which is found in the car Porsche Cayman 987 facelift (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ on board refueling vapour recovery w/o on board refueling vapour recovery (1 of 1)
2.9L 3.4L
3.4L 2.9L
BLK WIRE
BLK/GRN WIRE
BLU WIRE
CAMSHAFT SENSOR 1 CYLINDER 1-3
CAMSHAFT SENSOR 2 CYLINDER 4-6
COOLING SPORT WATER EXHAUST SHUT OFF SYSTEM VALVE VALVE
COOLING WATER SHUT OFF VALVE
DME CONTROL UNIT
ENGINE COMPARTMENT FAN HIGH RELAY
FROM
FUEL INJECTOR
FUSE HOLDER D (DIAGRAM 4 OF 5)
GRN WIRE
MASS AIR FLOW SENSOR
OIL TANK LEVEL VENT SENSOR VALVE
QUALITY CONTROL VALVE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
SECONDARY AIR PUMP RELAY
SPORT EXHAUST SYSTEM VALVE
TANK LEAKAGE DIAGNOSTICS MODULE
W/ ON BOARD REFUELING VAPOUR RECOVERY W/O ON BOARD REFUELING VAPOUR RECOVERY
Go to component -> Power distribution circuit (5 of 5) -> W/ ON BOARD REFUELING VAPOUR RECOVERY W/O ON BOARD REFUELING VAPOUR RECOVERY
