Porsche Cayman 987 facelift (2009-2012) term 30 power window Wiring diagrams
This page contains all the electrical diagrams for the component. term 30 power window, in which he is found in the car Porsche Cayman 987 facelift (2009-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram term 30 power window (1 of 4)
12 15 MIRROR HEATING + MIRROR HEATING -
19 5 6 TERM 31 CAN HIGH COMFORT CAN LOW COMFORT
7 11 MIRROR HEATER + MIRROR HEATING -
7 11 MIRROR HEATER MIRROR HEATING GND
BATTERY
BLK WIRE
BLK/RED WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR CONTROL UNIT
DRIVER'S MIRROR CONTROL UNIT
HOT AT ALL TIMES FUSE
HOT AT ALL TIMES FUSE HOLDER A FUSE
PASSENGER'S DOOR CONTROL UNIT
PASSENGER'S MIRROR CONTROL UNIT
RED/GRN WIRE
RED/WHT WIRE
TERM 30 POWER WINDOW
TERM 30 POWER WINDOW 5 6 CAN HIGH COMFORT CAN LOW COMFORT
TERM 31
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Heated mirrors circuit -> TERM 30 POWER WINDOW
Wiring diagram term 30 power window (2 of 4)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 ANTI-DAZZLE MIRROR + ANTI-DAZZLE MIRROR -
1 2 3 4 MEMORY TERM 31 POSITION ID TERM 58
1 3 10 2 5 4 7 12 MIRROR POTI POS X
20 6 5 TERM 30 POWER WINDOW CAN LOW COMFORT CAN HIGH COMFORT
6 5 CAN LOW COMFORT CAN HIGH COMFORT
BLK WIRE
BLK/RED WIRE
BLU/BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR CONTROL UNIT
DRIVER'S MIRROR ADJUSTMENT SWITCH
DRIVER'S MIRROR CONTROL UNIT
GRN WIRE
GRN/BLK WIRE
HOT AT ALL TIMES FUSE
HOT AT ALL TIMES FUSE HOLDER A FUSE
MEMORY SWITCH
MIRROR HEATING
MIRROR HEATING GND
MIRRORS SYSTEM
PASSENGER'S DOOR CONTROL UNIT
PASSENGER'S MIRROR CONTROL UNIT
POWER WINDOWS SYSTEM
RED/GRN WIRE
RED/WHT WIRE
TERM 15
TERM 30 POWER WINDOW
TERM 58
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Memory mirrors circuit -> TERM 30 POWER WINDOW
Wiring diagram term 30 power window (3 of 4)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 ANTI-DAZZLE MIRROR + ANTI-DAZZLE MIRROR -
1 3 10 2 5 4 7 12 11 MIRROR POTI POS X
22 12 7 6 TERM 58 OPERATING SW - MIRROR ADJUSTMENT MIRROR CHANGEOVER SW
6 5 CAN LOW COMFORT CAN HIGH COMFORT
AUTO ANTI-DAZZLE MIRROR CIRCUIT
BLK WIRE
BLK/RED WIRE
BLU/BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR CONTROL UNIT
DRIVER'S MIRROR ADJUSTMENT SWITCH
DRIVER'S MIRROR CONTROL UNIT
GRN WIRE
GRN/BLK WIRE
HOT AT ALL TIMES FUSE
HOT AT ALL TIMES FUSE HOLDER A FUSE
MIRROR HEATING
PASSENGER'S DOOR CONTROL UNIT
PASSENGER'S MIRROR CONTROL UNIT
POWER WINDOWS SYSTEM
RED/GRN WIRE
RED/WHT WIRE
TERM 30 POWER WINDOW
TERM 31
TERM 58
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Power mirror circuit -> TERM 30 POWER WINDOW
Wiring diagram term 30 power window (4 of 4)
19 5 6 TERM 31 CAN HIGH CAN LOW
BATTERY
BLK WIRE
BLK/ORG WIRE
BRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
BUTTON
CHANGEOVER SWITCH
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL UNIT
DRIVER POWER WINDOW SWITCH
FRONT/REAR
FUSE FUSE
FUSE HOLDER A
HOT AT ALL TIMES
LIGHT
LOCAL
LOWERING DOOR WINDOWS
PASSENGER
PASSENGER DOOR CONTROL UNIT
PASSENGER POWER WINDOW SWITCH
POWER WINDOWS)
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
TERM 30
TERM 30 POWER WINDOW
TERMINAL 31
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
Go to component -> Power windows circuit -> TERM 30 POWER WINDOW
