Porsche Cayman 987 facelift (2009-2012) tank leakage diagnostics module Wiring diagrams
This page contains all the electrical diagrams for the component. tank leakage diagnostics module, in which he is found in the car Porsche Cayman 987 facelift (2009-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram tank leakage diagnostics module (1 of 2)
2.9L 3.4L
3.4L 2.9L
BLK WIRE
BLK/GRN WIRE
BLU WIRE
CAMSHAFT SENSOR 1 CYLINDER 1-3
CAMSHAFT SENSOR 2 CYLINDER 4-6
COOLING SPORT WATER EXHAUST SHUT OFF SYSTEM VALVE VALVE
COOLING WATER SHUT OFF VALVE
DME CONTROL UNIT
ENGINE COMPARTMENT FAN HIGH RELAY
FROM
FUEL INJECTOR
FUSE HOLDER D (DIAGRAM 4 OF 5)
GRN WIRE
MASS AIR FLOW SENSOR
OIL TANK LEVEL VENT SENSOR VALVE
QUALITY CONTROL VALVE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
SECONDARY AIR PUMP RELAY
SPORT EXHAUST SYSTEM VALVE
TANK LEAKAGE DIAGNOSTICS MODULE
W/ ON BOARD REFUELING VAPOUR RECOVERY W/O ON BOARD REFUELING VAPOUR RECOVERY
Go to component -> Power distribution circuit (5 of 5) -> TANK LEAKAGE DIAGNOSTICS MODULE
Wiring diagram tank leakage diagnostics module (2 of 2)
1 2 3 4 5 6 7 8 9 IGN COIL 6 IGN COIL 4 IGN COIL 2 IGN COIL 5
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
BLU/VIO WIRE
BRIDGE PLUG (RELAY SUPPORT 1)
BRN WIRE
BRN/BLK BLK WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/PNK WIRE
BRN/RED WIRE
BRN/VIO WIRE
BUTTON SPORTS PDL VALUE SENS 1 GND PDL VALUE SENS 1 SIG
CLUTCH INTERLOCK SWITCH
CLUTCH PEDAL
COOLANT LEVEL SW
COOLING FANS SYSTEM
COOLING WATER VALVE
CRASH SHUT-DOWN
DME CONTROL UNIT
DMTL HEATING ELEMENT
DMTL PUMP DMTL VALVE
ELECTRONIC MUFFLERS SYSTEM
ENG COMPT BLWR RLY MFI+DI RELAY CTRL
ENG SPEED SENSOR ENG SPEED SENSOR
FUEL PUMP RELAY CTRL
GATEWAY CONTROL UNIT (LEFT KICK PANEL)
GRN/BLK WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/GRY WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
IGN COIL 1 CAMSHAFT ADJ 1 CAMSHAFT ADJ 2 IGN COIL 3
IGNITION COILS (CYLINDER HEAD COVER)
INJ VALVE/CYLINDER 2 INJ VALVE/CYLINDER 1
KNOCK SENS 1 KNOCK SENS 1
KNOCK SENS 2 KNOCK SENS 2
LED SPORTS EXHAUST COOLING WATER VALVE
OIL PRESSURE CAN HIGH CAN LOW
PDK CONTROL UNIT
PDL VALUE SENS 2 GND PDL VALUE SENS 2 SIG
PLUG SPARK
PRESSURE CTRL -
RED/BLK WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/VIO WIRE
RELEASE
SPARK PLUG
STARTER INTER LK
STARTING/CHARGING SYSTEM
SUPPLEMENTAL RESTRAINTS SYSTEM
TANK LEAKAGE DIAGNOSTICS MODULE
VIO WIRE
VIO/RED WIRE
WHT WIRE
WHT/BLK WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/RED WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 2.9l (3 of 3) -> TANK LEAKAGE DIAGNOSTICS MODULE
