Porsche Cayman 987 facelift (2009-2012) signal subwoofer - plus switched subwoofer Wiring diagrams
This page contains all the electrical diagrams for the component. signal subwoofer - plus switched subwoofer, in which he is found in the car Porsche Cayman 987 facelift (2009-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram signal subwoofer - plus switched subwoofer (1 of 2)
2 1 OUTPUT INPUT
ACTUATION + ACTUATION - WAKE UP TERM 31 TERM 30
BLU WIRE
BLU/BLK WIRE
BOSE AMPLIFIER
BOSE SUBWOOFER
BRN WIRE
CENTER SPEAKER
COUPE
DIAGNOSTICS
GP ELECTRONICS (AT LEFT SIDE OF DASH)
GRN WIRE
GRN/BLK WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES FUSE HOLDER E FUSE
LEFT DASHBOARD TWEETER SPEAKER
LEFT DOOR LOW RANGE SPEAKER
LEFT DOOR MID RANGE SPEAKER
LEFT REAR (+) LEFT REAR (-) RIGHT REAR (+) RIGHT REAR (-)
LEFT REAR SPEAKER
ORG/ WIRE
ORG/BRN WIRE
RED WIRE
RED/BRN WIRE
RF LOW RANGE SPEAKER (-) RF TWEETER (+) LF TWEETER (-) CENTER SPEAKER -
RIGHT DASHBOARD TWEETER SPEAKER
RIGHT DOOR LOW RANGE SPEAKER
RIGHT DOOR MID RANGE SPEAKER
RIGHT REAR SPEAKER
SIGNAL SUBWOOFER - PLUS SWITCHED SUBWOOFER
SOUND ACQUISITION MICROPHONE - SOUND ACQUISITION MICROPHONE +
SOUND SYSTEMS (OPTICAL
TERM 30 TERM 31 LF LOW RANGE SPEAKER (+)
VIO WIRE
VIO/BLK WIRE
WAVEGUIDE CIRCUIT)
WHT WIRE
WHT/BLK WIRE
WHT/BRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
Go to component -> Navigation circuit, with bose (3 of 3) -> SIGNAL SUBWOOFER - PLUS SWITCHED SUBWOOFER
