Porsche Cayman 987 facelift (2009-2012) right memory seat control unit Wiring diagrams
This page contains all the electrical diagrams for the component. right memory seat control unit, in which he is found in the car Porsche Cayman 987 facelift (2009-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
right memory seat control unit wiring diagram (1 of 2)
AIR BAG CONTROL UNIT
ALARM SIREN
BLK WIRE
BRN WIRE
CENTRAL LOCKING SYSTEM SWITCH
CLIMATRONIC CONTROL UNIT
DRIVER'S SIDE AIR BAG SENSOR
ELECTRICAL STATIC DISCHARGE
FAN FINAL STAGE
FRESH AIR CIRCULATING SERVO MOTOR
GLOVE COMPARTMENT MICRO SWITCH
GP AIR BAG (UNDER CENTER CONSOLE)
LEFT BUCKLE
LEFT RIGHT FRONT FRONT SENSOR SENSOR
MIDDLE VENTS LIGHT
NCA WIRE
PASM (DAMPTRONIC) CONTROL UNIT
PASSENGER AIR BAG OFF
PASSENGER'S SIDE AIR BAG SENSOR
REFRIGERANT PRESSURE SENSOR
RIGHT BUCKLE
RIGHT FRONT BRAKE PAD WEAR CONTROL SPEED SENSOR
RIGHT HEATED SPRAY JET
RIGHT MEMORY SEAT CONTROL UNIT
RIGHT POWER SEAT SWITCH
RIGHT REAR BRAKE PAD WEAR CONTACT SPEED SENSOR
RIGHT VENTS LIGHT
TO LEFT SEAT
TO RIGHT LEFT DOOR DOOR
TO RIGHT SEAT
WARNING LIGHT BUTTON
WEIGHT RECOGNITION CONTROL UNIT
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (3 of 4) -> RIGHT MEMORY SEAT CONTROL UNIT
right memory seat control unit wiring diagram (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
COMBINED STEERING WHEEL MODULE
COOLING WATER FAN CONTROL UNIT
CURRENT DISTRIBUTOR (BEHIND RIGHT SIDE OF
DASH)
DIAGNOSIS PLUG SOCKET
ENGINE COMPARTMENT FAN HIGH RELAY
FROM
FRONT END CONTROL UNIT
FUSE
FUSE FUSE
FUSE HOLDER B
FUSE HOLDER E (DIAGRAM 1 OF 5)
FUSE HOLDER F FUSE
GENERATOR B+ PLUG SOCKET (RIGHT SIDE OF TRANSMISSION)
GRN WIRE
HEADLIGHT WASHER RELAY RELAY SUPPORT 1 (UNDER LEFT SIDE OF DASH, IN FOOTWELL)
HEATER RELAY
INSTRUMENT CLUSTER
INTERIOR SENSOR
LEFT ALARM MEMORY SIREN SEAT CONTROL UNIT (NOT USED)
MIDI FUSE (EXHAUST)
ORG/ WIRE
PARK ASSIST CONTROL UNIT
RDK CONTROL UNIT
RED WIRE
RED/BLK WIRE
RELAY SUPPORT 1 (UNDER LEFT SIDE OF DASH, IN FOOTWELL)
RELAY SUPPORT 2 (LEFT SIDE OF REAR LUGGAGE COMPT)
RIGHT MEMORY SEAT CONTROL UNIT
SELECTOR LEVER CONTROL UNIT
SPORT CHRONO
STARTER
TILT SENSOR
TO EMERGENCY POWER SUPPLY RELAY 1 (DIAGRAM 3 OF 5)
TO MFI-DI RELAY (DIAGRAM 4 OF 5)
TO MICRO RELAY (DIAGRAM 4 OF 5)
TO TERMINAL 15 RELAY (DIAGRAM 3 OF 5)
VEHICLE ELECTRICAL SYSTEM CONTROL UNIT
WEIGHT PDK RECOGNITION CONTROL UNIT CONTROL UNIT
WHT WIRE
Go to component -> Power distribution circuit (2 of 5) -> RIGHT MEMORY SEAT CONTROL UNIT
