Porsche Cayman 987 facelift (2009-2012) lowering door windows wiring diagram
This page shows the only wiring diagram for the component.lowering door windows, which is found in the car Porsche Cayman 987 facelift (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
lowering door windows wiring diagram (1 of 1)
19 5 6 TERM 31 CAN HIGH CAN LOW
BATTERY
BLK WIRE
BLK/ORG WIRE
BRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
BUTTON
CHANGEOVER SWITCH
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL UNIT
DRIVER POWER WINDOW SWITCH
FRONT/REAR
FUSE FUSE
FUSE HOLDER A
HOT AT ALL TIMES
LIGHT
LOCAL
LOWERING DOOR WINDOWS
PASSENGER
PASSENGER DOOR CONTROL UNIT
PASSENGER POWER WINDOW SWITCH
POWER WINDOWS)
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
TERM 30
TERM 30 POWER WINDOW
TERMINAL 31
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
Go to component -> Power windows circuit -> LOWERING DOOR WINDOWS
