Porsche Cayman 987 facelift (2009-2012) high front end range control unit horn Wiring diagram
This page shows the only wiring diagram for the component.high front end range control unit horn, which is found in the car Porsche Cayman 987 facelift (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high front end range control unit horn (1 of 1)
AMPLIFIER
BATTERY
BLK WIRE
BRN WIRE
BRN/BLK WIRE
CONVERTIBLE COUPE 3 2
COOLING WATER FAN CONTROL UNIT
CORNER SENSITIVE HEADLIGHTS CONTROL UNIT
COUPE
DAYTIME RUNNING LIGHT
DIAGNOSTIC PLUG SOCKET
DRIVER'S DOOR CONTROL UNIT
EMERGENCY OPEN BUTTON
EXCEPT XENON, HALOGEN XENON, HALOGEN
FRONT FOG LIGHT
FRONT LOCK MICRO SWITCH
GP ELECTRONICS (AT LEFT SIDE OF DASH)
GP PSM
HIGH FRONT END RANGE CONTROL UNIT HORN
HOME LINK TRANSMITTER
LEFT HEADLIGHT ASSEMBLY
LUGGAGE LOW COMPARTMENT RANGE LID TWO TONE ACTUATOR HORN
MOBILE PHONE
NCA WIRE
PASSENGER'S DOOR CONTROL UNIT
PCM
PSM BRAKE CONTROL FLUID UNIT RESERVOIR
RATE OF TURN SENSOR
SIDE MARKER LIGHT
SIDE MARKER TURN SIGNAL LIGHT
SUBWOOFER
TELEPHONE HANDSET
TELEVISION TUNER
TELEVISION TUNER SHIELD
W/O BOSE
WHT WIRE
XENON, HALOGEN EXCEPT XENON, HALOGEN
Go to component -> Ground distribution circuit (1 of 4) -> HIGH FRONT END RANGE CONTROL UNIT HORN
