Porsche Cayman 987 facelift (2009-2012) engine compartment fan high relay Wiring diagrams
This page contains all the electrical diagrams for the component. engine compartment fan high relay, in which he is found in the car Porsche Cayman 987 facelift (2009-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
engine compartment fan high relay wiring diagram (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
COMBINED STEERING WHEEL MODULE
COOLING WATER FAN CONTROL UNIT
CURRENT DISTRIBUTOR (BEHIND RIGHT SIDE OF
DASH)
DIAGNOSIS PLUG SOCKET
ENGINE COMPARTMENT FAN HIGH RELAY
FROM
FRONT END CONTROL UNIT
FUSE
FUSE FUSE
FUSE HOLDER B
FUSE HOLDER E (DIAGRAM 1 OF 5)
FUSE HOLDER F FUSE
GENERATOR B+ PLUG SOCKET (RIGHT SIDE OF TRANSMISSION)
GRN WIRE
HEADLIGHT WASHER RELAY RELAY SUPPORT 1 (UNDER LEFT SIDE OF DASH, IN FOOTWELL)
HEATER RELAY
INSTRUMENT CLUSTER
INTERIOR SENSOR
LEFT ALARM MEMORY SIREN SEAT CONTROL UNIT (NOT USED)
MIDI FUSE (EXHAUST)
ORG/ WIRE
PARK ASSIST CONTROL UNIT
RDK CONTROL UNIT
RED WIRE
RED/BLK WIRE
RELAY SUPPORT 1 (UNDER LEFT SIDE OF DASH, IN FOOTWELL)
RELAY SUPPORT 2 (LEFT SIDE OF REAR LUGGAGE COMPT)
RIGHT MEMORY SEAT CONTROL UNIT
SELECTOR LEVER CONTROL UNIT
SPORT CHRONO
STARTER
TILT SENSOR
TO EMERGENCY POWER SUPPLY RELAY 1 (DIAGRAM 3 OF 5)
TO MFI-DI RELAY (DIAGRAM 4 OF 5)
TO MICRO RELAY (DIAGRAM 4 OF 5)
TO TERMINAL 15 RELAY (DIAGRAM 3 OF 5)
VEHICLE ELECTRICAL SYSTEM CONTROL UNIT
WEIGHT PDK RECOGNITION CONTROL UNIT CONTROL UNIT
WHT WIRE
Go to component -> Power distribution circuit (2 of 5) -> ENGINE COMPARTMENT FAN HIGH RELAY
engine compartment fan high relay wiring diagram (2 of 2)
2.9L 3.4L
3.4L 2.9L
BLK WIRE
BLK/GRN WIRE
BLU WIRE
CAMSHAFT SENSOR 1 CYLINDER 1-3
CAMSHAFT SENSOR 2 CYLINDER 4-6
COOLING SPORT WATER EXHAUST SHUT OFF SYSTEM VALVE VALVE
COOLING WATER SHUT OFF VALVE
DME CONTROL UNIT
ENGINE COMPARTMENT FAN HIGH RELAY
FROM
FUEL INJECTOR
FUSE HOLDER D (DIAGRAM 4 OF 5)
GRN WIRE
MASS AIR FLOW SENSOR
OIL TANK LEVEL VENT SENSOR VALVE
QUALITY CONTROL VALVE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
SECONDARY AIR PUMP RELAY
SPORT EXHAUST SYSTEM VALVE
TANK LEAKAGE DIAGNOSTICS MODULE
W/ ON BOARD REFUELING VAPOUR RECOVERY W/O ON BOARD REFUELING VAPOUR RECOVERY
Go to component -> Power distribution circuit (5 of 5) -> ENGINE COMPARTMENT FAN HIGH RELAY
