Porsche Cayman 987 facelift (2009-2012) 7 11 mirror heater mirror heating gnd Wiring diagram
This page shows the only wiring diagram for the component.7 11 mirror heater mirror heating gnd, which is found in the car Porsche Cayman 987 facelift (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 7 11 mirror heater mirror heating gnd (1 of 1)
12 15 MIRROR HEATING + MIRROR HEATING -
19 5 6 TERM 31 CAN HIGH COMFORT CAN LOW COMFORT
7 11 MIRROR HEATER + MIRROR HEATING -
7 11 MIRROR HEATER MIRROR HEATING GND
BATTERY
BLK WIRE
BLK/RED WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR CONTROL UNIT
DRIVER'S MIRROR CONTROL UNIT
HOT AT ALL TIMES FUSE
HOT AT ALL TIMES FUSE HOLDER A FUSE
PASSENGER'S DOOR CONTROL UNIT
PASSENGER'S MIRROR CONTROL UNIT
RED/GRN WIRE
RED/WHT WIRE
TERM 30 POWER WINDOW
TERM 30 POWER WINDOW 5 6 CAN HIGH COMFORT CAN LOW COMFORT
TERM 31
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Heated mirrors circuit -> 7 11 MIRROR HEATER MIRROR HEATING GND
