Porsche Cayman 987 facelift (2009-2012) 40 42 eng compt temp sen sens gnd Wiring diagrams
This page contains all the electrical diagrams for the component. 40 42 eng compt temp sen sens gnd, in which he is found in the car Porsche Cayman 987 facelift (2009-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 40 42 eng compt temp sen sens gnd (1 of 2)
1 2 GND BATT
1 2 LEFT FAN + LEFT FAN -
1 2 TERM 15 ACTUATION INPUT
17 22 SENS GND NTC WAGGER
2.9L 3.4L
25 36 37 43 54 41 ENG COMPT BLWR RLY CAN HIGH CAN LOW
40 42 ENG COMPT TEMP SEN SENS GND
ACTUATION TERM 15 FAN FINAL STAGE
AIR CONDITIONING COMPRESSOR (LEFT FRONT OF ENGINE)
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLU/ORG WIRE
BLU/YEL WIRE
BRN WIRE
BRN/PNK WIRE
BRN/WHT WIRE
CAN HIGH COMFORT
CAN LOW COMFORT
COMPUTER DATA LINES SYSTEM
COOLANT TEMPERATURE SENSOR (NTC) (ON ENGINE)
COOLING WATER FAN CONTROL UNIT
CU A/C
CURRENT DISTRIBUTOR (BEHIND RIGHT
DME CONTROL UNIT
ENGINE COMPARTMENT HIGH FAN RELAY
ENGINE COMPARTMENT PURGE FAN (CLEANER FAN) (LEFT FRONT SIDE OF ENGINE COMPT)
ENGINE COMPARTMENT TEMPERATURE SENSOR
ENGINE CONTROLS, TRANSMISSION SYSTEMS
FRONT END CONTROL UNIT (RIGHT SIDE OF FRONT LUGGAGE COMPT)
FUSE
FUSE HOLDER B
FUSE HOLDER D
HEATER RELAY
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE HOLDER F FUSE
HOT W/ DME RELAY ENERGIZED
LEFT COOLING WATER FAN
MIDI FUSE
NCA WIRE
ORG/ WIRE
PAS (DRIVER RECOGNITION) CONTROL UNIT (UNDER DASH, LEFT OF STEERING COLUMN)
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RELAY SUPPORT 1 (UNDER LEFT SIDE OF DASH, IN FOOTWELL)
RELAY SUPPORT 2 (LEFT SIDE OF REAR LUGGAGE COMPT)
RIGHT COOLING WATER FAN
SIDE OF DASH)
TANK LEAKAGE DIAGNOSTIC MODULE
TCRMX
TERM 87
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Automatic a/c circuit (2 of 2) -> 40 42 ENG COMPT TEMP SEN SENS GND
