Porsche Cayman 987 facelift (2009-2012) 2 8 can comfort high can comfort low Wiring diagrams
This page contains all the electrical diagrams for the component. 2 8 can comfort high can comfort low, in which he is found in the car Porsche Cayman 987 facelift (2009-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
2 8 can comfort high can comfort low wiring diagram (1 of 2)
2 8 CAN COMFORT HIGH CAN COMFORT LOW
37 38 6 CAN COMFORT HIGH CAN COMFORT LOW SPOILER SW MODULE
38 41 SPOILER MODE FUNC LIGHT SPORT MODE FUNC LIGHT
BLK WIRE
BLU/GRN WIRE
BRN WIRE
BRN/GRN WIRE
BUTTON MODULE
COMPUTER DATA LINES SYSTEM
DRIVE SPOILER (REAR FLAP)
FUSE
GRN WIRE
GROUND
GRY/RED WIRE
HOT AT ALL TIMES FUSE HOLDER A
ILLUMINATION
REAR CONTROL UNIT (UNDER DRIVER'S SEAT)
RED WIRE
SPOILER MODE FUNC LIGHT
SPOILER SW MODULE
SPORT MODE FUNC LIGHT
VEHICLE ELECTRICAL SYSTEM CONTROL UNIT
WHT WIRE
YEL WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
Go to component -> Active bodyworks circuit -> 2 8 CAN COMFORT HIGH CAN COMFORT LOW
2 8 can comfort high can comfort low wiring diagram (2 of 2)
1 2 3 4 5 TERM 15 TERM 31 BACKUP SIGNAL ACTUATION + ACTUATION -
1 2 ANTI-DAZZLE MIRROR + ANTI-DAZZLE MIRROR -
2 8 CAN COMFORT HIGH CAN COMFORT LOW
37 38 40 CAN COMFORT HIGH CAN COMFORT LOW BACKUP LIGHT SW
ANTI-DAZZLE INTERIOR MIRROR
BACKUP LIGHT
BACKUP LIGHT SWITCH (TOP RIGHT OF TRANSMISSION)
BLK WIRE
BLK/BLU WIRE
BLK/ORG WIRE
BRIDGE PLUG (RELAY SUPPORT 1)
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S MIRROR CONTROL UNIT
FUSE HOLDER C
GRN/BLK WIRE
HOT W/ TERMINAL 15 RELAY ENERGIZED FUSE
NCA WIRE
PASSENGER'S MIRROR CONTROL UNIT
RAIN SENSOR ORIENTATION LIGHT
REAR CONTROL UNIT
VEHICLE ELECTRICAL SYSTEM CONTROL UNIT
YEL WIRE
YEL/BLK WIRE
Go to component -> Auto anti-dazzling mirror circuit -> 2 8 CAN COMFORT HIGH CAN COMFORT LOW
