Porsche Cayman 987 facelift (2009-2012) 2 7 15 two-tone horn sply can low can high computer data lines system Wiring diagram
This page shows the only wiring diagram for the component.2 7 15 two-tone horn sply can low can high computer data lines system, which is found in the car Porsche Cayman 987 facelift (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 2 7 15 two-tone horn sply can low can high computer data lines system (1 of 1)
1 2 GROUND HORN
1 20 22 HIGH RANGE HORN GND LOW RANGE TWO- TONE HORN
2 7 15 TWO-TONE HORN SPLY CAN LOW CAN HIGH COMPUTER DATA LINES SYSTEM
9 8 CAN HIGH CAN LOW
BLK WIRE
BLK/ORG WIRE
BLK/YEL WIRE
BRN WIRE
COMBINED STEERING COLUMN MODULE
COMPUTER DATA LINES SYSTEM
CURRENT
ELECTRONIC STEERING WHEEL
FRONT END CONTROL UNIT (RIGHT SIDE OF FRONT LUGGAGE COMPT)
HIGH RANGE HORN
HORN SWITCH
HOT AT ALL TIMES FUSE DISTRIBUTOR (BEHIND RIGHT SIDE OF DASH)
LEFT TIPTRONIC BUTTON
LOW RANGE TWO-TONE HORN (NEAR RIGHT HEADLIGHT ASSEMBLY)
NTC BUTTON
RED WIRE
RIGHT TIPTRONIC BUTTON
VIO/BLK WIRE
W/O MSW
YEL WIRE
Go to component -> Horn circuit -> 2 7 15 TWO-TONE HORN SPLY CAN LOW CAN HIGH COMPUTER DATA LINES SYSTEM
