Porsche Cayman 987 facelift (2009-2012) 12 13 37 38 42 front hood open sw rear hood open sw can high can low gnd Wiring diagram

12 13 37 38 42 FRONT HOOD OPEN SW REAR HOOD OPEN SW CAN HIGH CAN LOW GND 12 5 16 17 19 CLS ALARM REAR HOOD MICRO SW FUNCTION LT CLS ALARM 2 8 11 COMPUTER DATA LINES SYSTEM CAN HIGH CAN LOW GND 3 6 BATT GND 7 15 35 COMPUTER DATA LINES SYSTEM CAN LOW CAN HIGH TERMINAL 15 BATT (LEFT) BATT (RIGHT) TAILGATE UNLOCK DVR BLK WIRE BLK/ORG WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BRN/BLK WIRE BRN/ORG WIRE BRN/WHT WIRE CATCH ACTUATOR CENTRAL LOCKING SWITCH COMPUTER DATA LINES SYSTEM CURRENT DISTRIBUTOR (BEHIND RIGHT SIDE OF DASH) EMERGENCY OPEN SWITCH EMERGENCY POWER PIN (UNDER LEFT SIDE OF DASH, AT KICK PANEL) EMERGENCY POWER SUPPLY RELAY FRONT END CONTROL UNIT (RIGHT SIDE OF FRONT LUGGAGE COMPT) FRONT LID FRONT LOCK MICRO SWITCH FUSE FUSE FUSE FUSE HOLDER A GRN WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ TERM 15 RELAY ENERGIZED FUSE HOLDER C FUSE LUGGAGE COMPARTMENT LID ACTUATOR POWER DISTRIBUTION SYSTEM REAR CONTROL UNIT (UNDER LEFT SEAT) REAR HOOD LOCK MICRO SWITCH REAR LID RED WIRE RED/BLK WIRE RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE SILL BUTTON MODULE TAILGATE RELEASE ACTUATOR TARGA LID VEHICLE ELECTRICAL SYSTEM CONTROL UNIT WHT/RED WIRE YEL WIRE YEL/RED WIRE YEL/WHT WIRE
