Radio circuit, with navigation, without bose for Porsche Cayman 987 (2005-2009)

1 2 3 4 5 6 7 8 RR+ RR- FR+ FR- FL+ FL- RL+ RL- 1 2 3 4 5 6 TERM 30 TERM 31 WAKE UP DIAGNOSIS ADL ANTENNA ASK OUT SW TEL MUTE TERM 30 OUTPUT ANTENNA BLK/BLU WIRE BLK/RED WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE CAN WAKE UP CD CHANGER (IF EQUIPPED) COMPUTER DATA LINES SYSTEM FIBER OPTICS FIBER OPTIC CABLES FIBER OPTICS FIBER OPTICS FIBER OPTIC CABLES FREE HANDED SPEAKING/ NOISE ENTRY MICROPHONE FUSE FUSE HOLDER D (UNDER LEFT SIDE OF DASH, AT KICK PANEL) GP ELECTRONICS (LEFT SIDE OF MIDDLE SUPPORT FRAME) GRN WIRE GRY WIRE GRY/BRN WIRE HOT AT ALL TIMES NCA WIRE RADIO/INFOSYSTEM PCM 2 RED WIRE RED/BRN WIRE RED/GRN WIRE TELEPHONE TELEPHONE - TELEPHONE + TELEPHONE LF GRD TELEPHONE LF IN MICROPHONE GROUND MICROPHONE 1 + MICROPHONE 2 + TERM 31 WAKE UP/DIAGNOSIS WHT WIRE WHT/BRN WIRE WHT/RED WIRE YEL/BLK WIRE YEL/BLU WIRE

ANTENNA (LEFT "A" PILLAR) ANTENNA (RIGHT "A" PILLAR) ANTENNA ALARM ANTENNA ALARM SHIELD ASK AMPLIFIER BLK WIRE BLK/RED WIRE BLU WIRE BLU/BRN WIRE BRN WIRE CENTER INSTRUMENT PANEL SPEAKER CENTER SPEAKER + FR- FL- INSTRUMENT PANEL RR- RL- CLS ALARM OUT SWITCHING ENTRANCE AM/FM 1/2 DIVERSITY ANTENNA FL+ DOOR SPEAKER FR+ DOOR SPEAKER PLUS SWITCHED FL- DOOR SPEAKER FR- DOOR SPEAKER GP ELECTRONICS (LEFT SIDE SIDE OF MIDDLE SUPPORT FRAME) GRY WIRE GRY/BRN WIRE HF IN 1 HF IN 2 HF OUT IF IN SWITCHING OUTPUT 2 SWITCHING OUTPUT 1 TERM 30 HIGH RANGE INSTRUMENT PANEL SPEAKER LEFT DOOR DEEP RANGE SPEAKER LEFT DOOR MIDDLE RANGE SPEAKER NCA WIRE PAS CONTROL UNIT (BEHIND LEFT SIDE OF DASH) RED WIRE RED/BRN WIRE RIGHT DOOR DEEP RANGE SPEAKER RIGHT DOOR MIDDLE RANGE SPEAKER SWITCHING ENTRANCE FM 3/4 WHT WIRE WHT/BLK WIRE WHT/BRN WIRE YEL WIRE YEL/BRN WIRE
