Porsche Cayman 987 (2005-2009) telephone lf in Wiring diagrams
This page contains all the electrical diagrams for the component. telephone lf in, in which he is found in the car Porsche Cayman 987 (2005-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram telephone lf in (1 of 2)
ADL
ANTENNA
ANTENNA (LEFT "A" PILLAR)
ANTENNA (RIGHT "A" PILLAR)
ANTENNA ALARM
ANTENNA ALARM SHIELD
BLK WIRE
BLK/BLU WIRE
BLU/GRN WIRE
BLU/YEL WIRE
BRN WIRE
CLS ALARM OUT SWITCHING ENTRANCE AM/FM 1/2
COMPUTER DATA LINES SYSTEM
DIVERSITY ANTENNA
FIBER OPTICS FIBER OPTICS 2 3 4
FIBER OPTICS FIBER OPTICS 5 6
FIBER OPTICS FIBER OPTICS FIBER OPTIC CABLES
GP ELECTRONICS (LEFT SIDE OF MIDDLE SUPPORT FRAME)
HF IN 1 HF IN 2 HF OUT IF IN SWITCHING OUTPUT 2 SWITCHING OUTPUT 1 TERM 30
NCA WIRE
PAS CONTROL UNIT (BEHIND LEFT SIDE OF DASH)
RADIO
RED WIRE
RED/GRN WIRE
SWITCHING ENTRANCE FM 3/4
TEL MUTE TERM 30 OUTPUT ANTENNA
TELEPHONE
TELEPHONE LF GRD
TELEPHONE LF IN
TERM 31
WAKE UP/DIAGNOSIS
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL/BLK WIRE
YEL/BLU WIRE
Go to component -> Radio circuit, with bose without navigation (1 of 2) -> TELEPHONE LF IN
Wiring diagram telephone lf in (2 of 2)
3 4 5 6 WAKE UP DIAGNOSIS
ADL
ANTENNA
ANTENNA (LEFT "A" PILLAR)
ANTENNA (RIGHT "A" PILLAR)
ANTENNA ALARM
ANTENNA ALARM SHIELD
BLK WIRE
BLK/BLU WIRE
BLU/GRN WIRE
BLU/YEL WIRE
BRN WIRE
CD CHANGER (IF EQUIPPED)
CLS ALARM OUT SWITCHING ENTRANCE AM/FM 1/2
COMPUTER DATA LINES SYSTEM
DIVERSITY ANTENNA
FIBER OPTICS FIBER OPTIC CABLES
FIBER OPTICS FIBER OPTICS FIBER OPTIC CABLES
FR- FR+ FL- FL+
FUSE
FUSE HOLDER D (UNDER LEFT SIDE OF DASH, AT KICK PANEL)
GP ELECTRONICS (LEFT SIDE OF MIDDLE SUPPORT FRAME)
GRY WIRE
GRY/BRN WIRE
HF IN 1 HF IN 2 HF OUT IF IN TERM 30 SWITCHING OUTPUT 1 SWITCHING OUTPUT 2
HOT AT ALL TIMES
LEFT DOOR DEEP RANGE SPEAKER
LEFT INSTRUMENT PANEL SPEAKER
NCA WIRE
PAS CONTROL UNIT (BEHIND LEFT SIDE OF DASH)
RADIO
RED WIRE
RED/BRN WIRE
RED/GRN WIRE
RIGHT DOOR DEEP RANGE SPEAKER
RIGHT INSTRUMENT PANEL SPEAKER
SWITCHING ENTRANCE FM 3/4
TEL MUTE TERM 30 OUTPUT ANTENNA
TELEPHONE
TELEPHONE LF GRD
TELEPHONE LF IN
TERM 30
TERM 31
WAKE UP/DIAGNOSIS
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL/BLK WIRE
YEL/BLU WIRE
Go to component -> Radio circuit, without bose without navigation -> TELEPHONE LF IN
