Porsche Cayman 987 (2005-2009) sensors gnd Wiring diagram
This page shows the only wiring diagram for the component.sensors gnd, which is found in the car Porsche Cayman 987 (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sensors gnd (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 PINS 19-28 NOT USED SPEAKER
1 2 3 4 5 6 7 8 9 10 11 12 SENSOR 1 SENSOR 2 SENSOR 3 SENSOR 4 SENSORS +
2 1 3 SIGNAL
2 3 1 SIGNAL
BLK WIRE
BLK/BLU WIRE
BLK/ORG WIRE
BRIDGE PLUG
BRN WIRE
BRN/BLK WIRE
DIAGNOSIS
DIAGNOSIS PLUG SOCKET (BELOW LEFT SIDE OF DASH)
FUSE HOLDER C (UNDER LEFT SIDE OF DASH, AT LEFT KICK PANEL) FUSE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT W/ TERM 15 RELAY ENERGIZED
INSTRUMENT CLUSTER
ORG/ WIRE
ORG/BLU WIRE
PARK ASSIST INPUT
PARKING ASSISTANT CONTROL UNIT (UNDER DRIVER'S SEAT)
RED/GRY WIRE
REVERSE SIG
SENSORS GND
SIGNAL
TERM 15
TERM 31
ULTRASONIC SENSOR 1 (RIGHT REAR)
ULTRASONIC SENSOR 2 (MIDDLE RIGHT REAR)
ULTRASONIC SENSOR 3 (MIDDLE LEFT REAR)
ULTRASONIC SENSOR 4 (LEFT REAR)
Go to component -> Parking assistant circuit -> SENSORS GND
