Porsche Cayman 987 (2005-2009) seat rear up Wiring diagram
This page shows the only wiring diagram for the component.seat rear up, which is found in the car Porsche Cayman 987 (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram seat rear up (1 of 1)
BACKREST BACK
BACKREST FWD
BLK/BRN WIRE
BLK/PNK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BRN/BLU WIRE
BRN/GRY WIRE
BRN/WHT WIRE
BRN/YEL WIRE
FRONT SEAT CUSHION HEIGHT CONTROL MOTOR
GRN/BLK WIRE
GRY/BLK WIRE
GRY/GRN WIRE
LEFT MEMORY SEAT CONTROL UNIT (UNDER LEFT SEAT)
LONGITUDINAL BACK
LONGITUDINAL FWD
LUMBAR BACK
LUMBAR DOWN
LUMBAR FWD
LUMBAR UP
POWER SEAT SWITCH
REAR SEAT CUSHION HEIGHT CONTROL MOTOR
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
SEAT BACK FORWARD CONTROL MOTOR
SEAT BACKREST CONTROL MOTOR
SEAT FRONT DOWN
SEAT FRONT UP
SEAT REAR DOWN
SEAT REAR UP
VIO WIRE
VIO/BRN WIRE
WHT/BLK WIRE
WHT/GRN WIRE
YEL/BLK WIRE
YEL/GRN WIRE
Go to component -> Memory seat circuit (2 of 2) -> SEAT REAR UP
