Porsche Cayman 987 (2005-2009) right comfort power seat switch Wiring diagram
This page shows the only wiring diagram for the component.right comfort power seat switch, which is found in the car Porsche Cayman 987 (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right comfort power seat switch (1 of 1)
BATTERY
BLK WIRE
BLU WIRE
BRN WIRE
CIGAR LIGHTER
CURRENT DISTRIBUTOR
DRIVER DOOR CONTROL UNIT REAR CONTROL UNIT
FRONT END CONTROL UNIT
FUSE
FUSE FUSE
FUSE HOLDER A
FUSE HOLDER E FUSE
FUSEHOLDER D (DIAGRAM 4 OF 4)
GRN WIRE
GRY WIRE
LEFT COMFORT POWER SEAT SWITCH
LEFT POWER SEAT CONTROL UNIT
LEFT SEAT WIDTH ADJUSTMENT SWITCH
ONBOARD COMPUTER NETWORK CONTROL UNIT
PACKAGE TRAY PLUG SOCKET
PASSENGER DOOR CONTROL UNIT
PLUG SOCKET 2
PSM CONTROL UNIT
REAR CONTROL UNIT
REAR WINDOW DEFOGGER RELAY
RED WIRE
RIGHT COMFORT POWER SEAT SWITCH
RIGHT SEAT WIDTH ADJUSTMENT SWITCH
TO EMERGENCY POWER SUPPLY RELAY 2 (DIAGRAM 3 OF 4)
W/ MEMORY W/O MEMORY
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 4) -> RIGHT COMFORT POWER SEAT SWITCH
