Porsche Cayman 987 (2005-2009) rain sensor orientation light Wiring diagram
This page shows the only wiring diagram for the component.rain sensor orientation light, which is found in the car Porsche Cayman 987 (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rain sensor orientation light (1 of 1)
1 2 3 4 5 TERM 15 TERM 31 BACK UP SIGNAL ACTUATION + ACTUATION -
ANTI-DAZZLE INTERIOR MIRROR
ANTI-DAZZLE MIRROR + ANTI-DAZZLE MIRROR -
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLK/ORG WIRE
BLK/YEL WIRE
BRIDGE PLUG (RELAY SUPPORT 1)
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CURRENT DISTRIBUTOR FUSE
FUSE
FUSE HOLDER B (UNDER LEFT SIDE OF DASH, AT KICK PANEL) FUSE
FUSE HOLDER C (UNDER LEFT SIDE OF DASH, AT KICK PANEL) FUSE
GRN WIRE
GRN/BLK WIRE
GRY/BLU WIRE
HEADLIGHT CLEANER PUMP RELAY
HEADLIGHT WASHING CONTROL UNIT
HEADLIGHT WASHING FLUID PUMP
HOT AT ALL TIMES
HOT IN RUN OR START
HOT WITH TERM 15 RELAY ENERGIZED
LEFT HEATED SPRAY JET
MAXIFUSE (FAN) (RIGHT SIDE OF FRONT LUGGAGE COMPT)
MIRROR CINTROL UNIT
MIRRORS SYSTEM
NCA WIRE
ON-BOARD COMPUTER NETWORK CONTROL UNIT (UNDER LEFT SIDE OF DASH)
RAIN SENSOR ORIENTATION LIGHT
RED WIRE
RED/BLK WIRE
RED/GRY WIRE
RIGHT HEATED SPRAY JET
WASHING FLUID PUMP
WINDSHIELD WASHING FLUID PUMP
WINDSHIELD WIPER MOTOR
WIPER MOTOR STAGE 1
YEL/BLK WIRE
YEL/BLU WIRE
Go to component -> Front wiper/washer & headlamp washer circuit, with rain sensor -> RAIN SENSOR ORIENTATION LIGHT
