Porsche Cayman 987 (2005-2009) off on backrest lumbar valve block Wiring diagram
This page shows the only wiring diagram for the component.off on backrest lumbar valve block, which is found in the car Porsche Cayman 987 (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram off on backrest lumbar valve block (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 BATT GND BATT (ELECTRONIC)
BACKREST
BLK WIRE
BLK/PNK WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BRN WIRE
BRN/GRY WIRE
BRN/WHT WIRE
CAN COMFORT HIGH
CAN COMFORT LOW GND (ELECTRONIC)
COMPUTER DATA LINES SYSTEM
GRN/BLK WIRE
GRN/WHT WIRE
GRY/BLK WIRE
GRY/GRN WIRE
LEFT MEMORY SEAT CONTROL UNIT (UNDER LEFT SEAT)
LUMBAR DISTANCE MEASUREMENT SENSOR (AIR CHAMBER ABOVE)
LUMBAR DISTANCE MEASUREMENT SENSOR (AIR CHAMBER BELOW)
LUMBAR PUMP MOTOR
NCA WIRE
OFF ON BACKREST LUMBAR VALVE BLOCK
OFF ON SEAT
ON OFF ON OFF SEAT BACKREST VALVE BLOCK
PUMP MOTOR
RED WIRE
RED/BLK WIRE
RED/GRY WIRE
SEAT WIDTH ADJUSTMENT SWITCH
SEAT)
VIO WIRE
WHT WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/WHT WIRE
Go to component -> Memory seat circuit (1 of 2) -> OFF ON BACKREST LUMBAR VALVE BLOCK
