Porsche Cayman 987 (2005-2009) left taillight assembly back- up light Wiring diagram
This page shows the only wiring diagram for the component.left taillight assembly back- up light, which is found in the car Porsche Cayman 987 (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left taillight assembly back- up light (1 of 1)
17 22 BATT (RIGHT) BACK-UP LIGHT
2 8 11 CAN HIGH CAN LOW GND
3 6 42 BATT GND GND
37 38 40 CAN HIGH CAN LOW BACK-UP LIGHT SWITCH
A/T M/T
ANTI- DAZZLING INSIDE MIRROR
BACK- UP LIGHT
BACK-UP LIGHT SWITCH (ON TOP RIGHT OF TRANS- MISSION)
BATT (LEFT)
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
CURRENT DISTRIBUTOR
EMERGENCY POWER PIN
EMERGENCY POWER SUPPLY RELAY 1
EMERGENCY POWER SUPPLY RELAY 2
FUSE
FUSE HOLDER A (UNDER LEFT SIDE OF DASH, AT LEFT KICK PANEL)
GRN WIRE
HOT AT ALL TIMES
LEFT TAILLIGHT ASSEMBLY BACK- UP LIGHT
NCA WIRE
ONBOARD NETWORK CONTROL MODULE (UNDER LEFT SIDE OF DASH)
PARKING ASSISTANT CONTROL UNIT (UNDER DRIVER'S SEAT)
POWER DISTRIBUTION SYSTEM
REAR CONTROL UNIT (UNDER DRIVER'S SEAT)
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RIGHT TAILLIGHT ASSEMBLY
YEL WIRE
Go to component -> Back-up lamps circuit -> LEFT TAILLIGHT ASSEMBLY BACK- UP LIGHT
